NEUTRIK speakON SPX Series Assembly Instruction

R
ASSEMBLY INSTRUCTION
NL2FX / NL2FRX
speakON SPX Series Lockable Loudspeaker Connector
IMPORTANT SAFETY INSTRUCTION
Electrical Rating acc. UL & CSA:
USR: 40A/250V, CNR: 25A/250V
A
1.
B
Cable O.D. 6.0 - 10.0 mm
[0.24 - 0.39"]
Wire size 1.5 - 4 mm
(AWG 12)
C
1-
E
BDA 348
®
"CAUTION: NOT FOR INTERRUPTING CURRENT"
"
2.
25 mm [1.0"]
2
12 mm [0.5"]
1+
D
ATTENTION: NE PAS UTILISER POUR COUPER LE COURANT"
Assembly of the Connector:
A
Place bushing and chuck over cable.
B
Prepare cable as shown.
Important is the stripping length of 25 mm and
12 mm.
Insert wires into terminals and secure clamp
C
terminals with screw driver (POZIDRIV # 1)
at max. torque 0.8 Nm.
For 6 mm
sheet and solder.
D
Push chuck up to housing .
Important: Align the chuck by positioning
the nose into the recess.
E
Finish installation by turning the bushing
onto the connector.
INFO to the screw driver:
POZIDRIV # 1
E
remove screws, clamping
2 (AWG 10)
X
DO NOT USE!
® Philips
®
