Summary of Contents for Trotec PAE 10
- Page 1 PAE 10 OPERATING MANUAL AIR COOLER...
-
Page 2: Table Of Contents
• Check accessories and connection parts for possible Information marked with this symbol indicates that the damage prior to every use of the device. Do not use any operating manual must be observed. defective devices or device parts. air cooler PAE 10... - Page 3 • Ice packs are not toys. Keep away from children and animals. • Never open an ice pack. The liquid inside the ice packs can be harmful to health. • Do not eat the ice that may form on the ice packs. Health hazard! air cooler PAE 10...
-
Page 4: Information About The Device
2. In an emergency, disconnect the device from the mains feed-in: Hold onto the mains plug while pulling the power cable out of the mains socket. 3. Do not reconnect a defective device to the mains. air cooler PAE 10... -
Page 5: Transport And Storage
• Place no further devices or objects on top of the device to Water tank with filling level indication and water prevent it from being damaged. outlet with rubber stopper (not depicted) Wheels Air inlet with air filter and honeycomb filter Air filter Honeycomb filter air cooler PAE 10... -
Page 6: Assembly And Start-Up
• Set the device up in an upright and stable position. • Do not create tripping hazards when laying the power cable or other electric cables, especially when positioning the device in the middle of the room. Use cable bridges. air cooler PAE 10... - Page 7 4. Close the water tank (5) again. 2. Ensure the tight fit of the rubber stopper (5a), for otherwise there might be uncontrolled water leakage. 5. Make sure that the device is neither damp nor wet on the outside. Otherwise wipe it dry. air cooler PAE 10...
-
Page 8: Operation
Switching the swing function on and off 15 COOL button Switching the air cooling mode on and 16 Rotary control For switching the device on and off button Automatic switch-off timer function (steplessly adjustable between 1 min and 120 min) air cooler PAE 10... - Page 9 ð The device is now in standby mode. Info If possible, change the water on a daily basis to prevent bacterial growth. Info Optionally, you can put ice packs into the water tank for additional cooling. air cooler PAE 10...
-
Page 10: Air Cooler Pae
• Hold onto the mains plug while pulling the power cable out of the mains socket. • Empty and clean the water tank (see chapter Maintenance). • Clean the device according to the Maintenance chapter. • Store the device according to the Storage chapter. air cooler PAE 10... -
Page 11: Available Accessories
• Wait for 10 minutes before restarting the device. If the Designation Article number device is not starting, have the electrics checked by a Evaporation filter PAE 10 7.710.000.841 specialist company or by Trotec. The device works with reduced or no capacity: •... -
Page 12: Maintenance
10. Date: ........11. Date: ........12. Date: ........Signature: ........ Signature: ......... Signature: ......... Signature: ......... 13. Date: ......... 14. Date: ........15. Date: ........16. Date: ........Signature: ........ Signature: ......... Signature: ......... Signature: ......... air cooler PAE 10... - Page 13 Protect electrical components from moisture. Do not use any aggressive cleaning agents such as cleaning sprays, solvents, alcohol-based or abrasive cleaners to dampen the cloth. 6. Dry the inside of the water tank with a lint-free cloth. air cooler PAE 10...
- Page 14 1. Remove the air filter from the device. 2. Thoroughly rinse the water tank. 3. Clean the tank using a mild cleaning agent (no detergent!). 4. Remove all calcium deposits in the water tank. air cooler PAE 10...
- Page 15 If you want to continue using the device: • Reconnect the device to the mains. If you do not intend to use the device for a considerable time: • Store the device according to the Storage chapter. air cooler PAE 10...
-
Page 16: Technical Annex
Weight 5 kg Dimensions 324 x 200 x 634 mm (length x width x height) Minimum distance to walls and other objects: top (A): 20 cm rear (B): 20 cm sides (C): 20 cm front (D): 20 cm air cooler PAE 10... - Page 17 Trotec GmbH & Co. KG Grebbener Str. 7 D-52525 Heinsberg +49 2452 962-400 +49 2452 962-200 info@trotec.com www.trotec.com...
