5. Using a 15/16'' hex wrench, loosen the locknut (E) that secures the pin (F) to the head end forging assembly (Figure 10).
6. Using a 3/8'' Allen wrench, adjust the pin so there is maximum clearance between the foot end cover assembly during
loading and unloading.
N N o o t t e e - - The pin must lock into the head end of the fastener while loaded.
7. Using a 15/16'' hex wrench, tighten the locknut that secures the pin to the head end forging assembly.
8. Verify proper operation of the product before returning it to service.
N N o o t t e e - - You must repair the cot and P P e e r r f f o o r r m m a a n n c c e e - - L L O O A A D D to avoid recurring damage to the foot end cover assembly.
EN 20
A
C
D
F F i i g g u u r r e e 9 9 – – F F o o o o t t e e n n d d c c o o v v e e r r a a s s s s e e m m b b l l y y
F F i i g g u u r r e e 1 1 0 0 – – H H e e a a d d e e n n d d f f o o r r g g i i n n g g a a s s s s e e m m b b l l y y
B
C
A
