Specifications
To achieve rated accuracy, allow the instrument to settle for 20 minutes. When
subjected to extreme temperatures, allow extra time for internal temperatures to
stabilize. Because of temperature compensated calibration, the Handyscope HS5
will settle within specified accuracy regardless of the surrounding temperature.
9.1

Acquisition system

Number of input channels
CH1, CH2
Type
Resolution
Accuracy
Range
Coupling
Impedance
Maximum voltage
Bandwidth (-3dB)
at 75% of full scale input
AC coupling cut off freq. (-3dB)
SureConnect
Maximum voltage on connection 200 V (DC + AC peak <10 kHz)
Resistance measurement
Ranges
Accuracy
Response time (to 95%)
Maximum sampling rate
8 bit, 12 bit
Measuring 1 channel
Measuring 2 channels
14 bit
16 bit
Maximum streaming rate
8 bit
Measuring 1 channel
Measuring 2 channels
12 bit, 14 bit
Measuring 1 channel
Measuring 2 channels
16 bit
Memory per channel
Measuring 1 channel
Measuring 2 channels
2 analog
BNC
Single ended
8, 12, 14, 16 bit user selectable
0.25% of full scale ± 1 LSB
±200 mV to ±80 V full scale
AC/DC
1 MΩ / 25 pF
200 V (DC + AC peak <10 kHz)
Ch1
250 MHz
±1.5 Hz
Optionally available (option S)
Optionally available (option S)
100 Ohm to 2 MOhm full scale
1%
<10 µs
HS5-540
500 MS/s
200 MS/s
100 MS/s
6.25 MS/s
1
HS5-540
40 MS/s
20 MS/s
20 MS/s
10 MS/s
6.25 MS/s
1 On some computers, the highest streaming rates may not be available,
due to computer restrictions.
Standard model
128 KiSamples
128 KiSamples
Ch2
100 MHz
HS5-530 HS5-220
500 MS/s 200 MS/s
200 MS/s 100 MS/s
100 MS/s 50 MS/s
6.25 MS/s 3.125 MS/s
HS5-530 HS5-220
40 MS/s 20 MS/s
20 MS/s 10 MS/s
20 MS/s 10 MS/s
10 MS/s 5 MS/s
6.25 MS/s 3.125 MS/s
XM Option
64 MSamples
32 MSamples
Specifications
9
HS5-110 HS5-055
100 MS/s 50 MS/s
50 MS/s 20 MS/s
20 MS/s 10 MS/s
1.25 MS/s 625 kS/s
HS5-110 HS5-055
10 MS/s 4 MS/s
4 MS/s 2 MS/s
5 MS/s 2 MS/s
2 MS/s 1 MS/s
1.25 MS/s 625 kS/s
