Handyscope HS5
Model 540
Model 530
Model 220
Model 110
Model 055
The Handyscope HS5 is available with two memory configurations, these are:
Memory
Standard model
Option XM
Optionally available for the Handyscope HS5 are SureConnect connection test
and resistance measurement. SureConnect connection test tells you immediately
whether your test probe or clip actually makes electrical contact or not. No more
doubt whether your probe doesn't make contact or there really is no signal. This
is useful when surfaces are oxidized and your probe cannot get a good electrical
contact. Simply activate the SureConnect and you know whether there is con-
tact or not. Also when back probing connectors in confined places, SureConnect
immediately shows whether the probes make contact or not.
Models of the Handyscope HS5 with SureConnect come with resistance measure-
ment on all channels. Resistances up to 2 MOhm can be measured directly. Re-
sistance can be shown in meter displays and can also be plotted versus time in a
graph, creating an Ohm scope.
With the accompanying software the Handyscope HS5 can be used as an oscil-
loscope, a spectrum analyzer, a true RMS voltmeter or a transient recorder. All
instruments measure by sampling the input signals, digitizing the values, process
them, save them and display them.
3.1

Sampling

When sampling the input signal, samples are taken at fixed intervals. At these
intervals, the size of the input signal is converted to a number. The accuracy of this
number depends on the resolution of the instrument. The higher the resolution,
the smaller the voltage steps in which the input range of the instrument is divided.
The acquired numbers can be used for various purposes, e.g. to create a graph.
6
Chapter 3
Channels
CH1 40 MS/s
CH1+CH2 20 MS/s
CH1 40 MS/s
CH1+CH2 20 MS/s
CH1 20 MS/s
CH1+CH2 10 MS/s
CH1 10 MS/s
CH1+CH2
CH1
CH1+CH2
Table 3.2: Maximum streaming rates
Model 540 Model 530 Model 220 Model 110 Model 055
128 KiS 128 KiS
32 MiS 32 MiS
Table 3.3: Maximum record lengths per channel
Resolution
8 bit 12/14 bit
20 MS/s
10 MS/s
20 MS/s
10 MS/s
10 MS/s
5 MS/s
5 MS/s
4 MS/s 2 MS/s
4 MS/s 2 MS/s
2 MS/s 1 MS/s
128 KiS
32 MiS
16 bit
6.25 MS/s
6.25 MS/s
3.125 MS/s
1.25 MS/s
625 kS/s
128 KiS 128 KiS
32 MiS 32 MiS
