King Kooker CSR2G Assembly Instructions And Use And Care Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
English
OUTDOOR COOKERS
CSR2G
ASSEMBLY INSTRUCTIONS
AND
USE AND CARE MANUAL
__________
MODEL/SERIAL #
THE INSTRUCTION MANUAL CONTAINS IMPORTANT INFORMATION NECESSARY
FOR THE PROPER ASSEMBLY AND SAFE USE OF THE APPLIANCE.
READ AND FOLLOW ALL WARNINGS AND INSTRUCTIONS BEFORE ASSEMBLING
AND USING THE APPLIANCE. FOLLOW ALL WARNINGS AND INSTRUCTIONS WHEN
USING THE APPLIANCE.
KEEP THIS MANUAL FOR FUTURE REFERENCE.
METAL FUSION, INC.
712 St. George Avenue.
Jefferson, LA 70121
If you have any problems or questions
Call Us Toll Free at
1-800-783-3885
7:30 A.M. to 3:30 P.M. CST • Monday through Friday
(504) 736-0201
www.kingkooker.com
FAILURE TO FOLLOW THESE INSTRUCTIONS
AND WARNINGS COULD RESULT IN FIRE, EXPLOSION, BURN HAZARD OR CARBON
MONOXIDE POISONING WHICH COULD CAUSE PROPERTY DAMAGE,
PERSONAL INJURY OR DEATH.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CSR2G and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for King Kooker CSR2G

Summary of Contents for King Kooker CSR2G

  • Page 1 English OUTDOOR COOKERS CSR2G ASSEMBLY INSTRUCTIONS USE AND CARE MANUAL __________ MODEL/SERIAL # THE INSTRUCTION MANUAL CONTAINS IMPORTANT INFORMATION NECESSARY FOR THE PROPER ASSEMBLY AND SAFE USE OF THE APPLIANCE. READ AND FOLLOW ALL WARNINGS AND INSTRUCTIONS BEFORE ASSEMBLING AND USING THE APPLIANCE. FOLLOW ALL WARNINGS AND INSTRUCTIONS WHEN USING THE APPLIANCE.

  • Page 2: Warnings

    DANGER FOR YOUR SAFETY If you smell gas: 1. Shut off gas to the appliance. 2. Extinguish any open flame. 3. If odor continues, keep away from the appliance and immediately call your Fire Department. FAILURE TO FOLLOW THESE INSTRUCTIONS COULD RESULT IN FIRE OR EXPLOSION WHICH COULD CAUSE PROPERTY DAMAGE, PERSONAL INJURY OR DEATH.
  • Page 3 READ AND UNDERSTAND BEFORE USING THIS PRODUCT Throughout this manual the words appliance, cooker, fryer/boiler, burner and stove will be used interchangeably to refer to the King Kooker Outdoor Cooker. ® This is an ATTENDED appliance. Do NOT leave this appliance unattended while the burner is lit or while heating oil, grease, water or cooking food.
  • Page 4 Failure to follow these instructions and warnings could result in fire or explosion which could cause property damage, personal injury or death. 21) This appliance is not intended for commercial use. 22) Use King Kooker appliances only in accordance with state and local ordinances, ®...

  • Page 5: Table Of Contents

    READ AND UNDERSTAND ALL INSTRUCTIONS BEFORE USING YOUR KING KOOKER ® PRODUCT TABLE OF CONTENTS Warnings........................2-4 Table of Contents .

  • Page 6: Warranty

    METAL FUSION, INC. LIMITED ONE-YEAR WARRANTY WHAT THIS WARRANTY COVERS This warranty covers all components of this outdoor cooker to be free from defects in materials and workmanship, with the exceptions stated below. HOW LONG COVERAGE LASTS This warranty runs for one year from the date of purchase. Please keep your receipt with this manual for future reference.

  • Page 7: Owner's Registration

    OWNER’S REGISTRATION Dear Customer, Thank you for purchasing a King Kooker ! Please take a moment to fill ® out your registration form and return it to us. We are always happy to hear suggestions and comments from our customers about our products. Completion of this registration allows us to contact you if the need arises.
  • Page 8 TAPE HERE FOLD ________________________ ________________________ Place Stamp ________________________ Here METAL FUSION, INC. 712 St. George Avenue Jefferson, LA 70121 FOLD...

  • Page 9: Section I - King Kooker ® Outdoor Cooker Assembly

    THE USE AND CARE MANUAL MUST BE READ AND UNDERSTOOD BEFORE USING THE APPLIANCE Throughout this manual the words appliance, cooker, fryer/boiler, burner and stove will be used interchangeably to refer to the King Kooker Outdoor Cooker. ® TOOLS REQUIRED: TORQUE WRENCH or ADJUSTABLE WRENCH, SCREWDRIVER, LEAK TESTING SOLUTION Before assembling, check that all cooker components are included in the shipping carton.
  • Page 10 1. Flip cooker frame upside down and place on a flat surface. 2. Install the four legs into the top frame. Insert legs fully into the leg receivers. Tighten with supplied wing head bolts (4). See Figure 1. Turn frame right side up. Make sure legs are locked in position and unit stands sturdily.
  • Page 11 4. The cooker includes a griddle as an accessory. When cooking with a pot(s), do not install the griddle. Follow the below directions for installation of the griddle and drip pan: a. The supplied drip pan is to be used when using the griddle. The drip pan is designed to collect any grease drippings which drain through the hole in the griddle channel.
  • Page 12 6. Hose Assembly Instructions - Tighten the 3/8 female flare swivel ending of the hose and regulator onto the manifold with a torque wrench, up to a torque of 95 to 105 lb./in. Alternatively, hand tighten securely and then, using a wrench, tighten an additional 1-1 1/2 turns. The hose to manifold connection must be tightened and leak tested (see Leak Test instructions on page 14) before using the appliance.

  • Page 13: Section Ii - Use And Care Of King Kooker ® Outdoor Cookers And Accessories

    212°F(100°C). The temperature of hot oil should never be allowed to exceed 350°F(177°C). IMPORTANT: Oil can ignite at high temperatures. Most King Kooker ® thermometers have a Red Zone above 350°F(177°C) to signify Danger. Never allow the temperature to exceed 350°F(177°C). If the temperature goes above 350°F(177°C) immediately turn the burner and gas supply OFF and wait for the temperature to decrease to below...

  • Page 14: Lp Gas Cylinder Information

    LP GAS CYLINDER INFORMATION King Kooker ® Outdoor Cookers are manufactured for use with 20lb. (9 kg) LP Gas Cylinders. Important information to remember about LP Gas cylinders include: Always read and follow the cylinder manufacturer’s instructions. Make sure that the gas cylinder is not overfilled. The maximum weight of a properly filled 20 lb. (9 kg) LP gas cylinder is approximately 38 lbs (17 kg).

  • Page 15: Placement Instructions

    Do NOT use any pot larger than the recommended size for your cooker as listed below: Model # Maximum Pot Size Pot - Height/Diameter CSR2G 22qts. (20.82 L) 11.5”H (29.21 cm) X 12.5”D (31.75 cm) (When cooking with a pot(s), do not install the griddle.) * Models may vary from picture.

  • Page 16: Lighting And Operating Instructions

    LIGHTING AND OPERATING INSTRUCTIONS THE COOKER MUST NOT BE LIT UNTIL THE PRECEDING PLACEMENT INSTRUCTIONS HAVE BEEN COMPLETELY FOLLOWED. *Your model has multiple control knobs that work independently. Follow below instructions for each control knob and casting. Check the cooker to make sure that it is set up as per the diagram (Figure 1). Make certain the control knobs are turned to the “OFF”...
  • Page 17 CYLINDER CONTROL VALVE FIGURE 1 * Model may vary from picture. Turn triangle handle toward ON (Counterclockwise) 20 lb. LP Gas Cylinder FIGURE 2 FIGURE 3 FIGURE 4 PAPERBOOK MATCH MULTI-PURPOSE LIGHTER LIGHTING LIGHTING HOLE HOLE FIGURE 5 Turn the control knob toward the “ON” position until ignition occurs.

  • Page 18: Turning Off And Storing The Cooker After Use

    100°F (38°C)]. ® After each use turn OFF the King Kooker at the control knob(s) first, then at the gas cylinder valve. Check to make sure there is no flame and all valves are off. Do not leave the cooker until it has cooled completely.
  • Page 19 To check for possible blockages in the casting(s), follow the directions for your model below: The gas handling components of your cooker (castings/manifold) have been pre-assembled for your conveniance. Use care when following the below directions as gas handling components can easily be damaged if mishandled.

  • Page 20: Griddle Use And Care Instructions

    STEEL GRIDDLE USE AND CARE INSTRUCTIONS The steel griddle included in your package needs to be cleaned before initial use. After each use of the steel griddle it also needs to be cleaned and properly stored to prevent rusting. Follow the below instructions for proper care and cleaning of your steel griddle.

  • Page 21: Caring For Aluminum And Cast Iron Cookware

    TIPS FOR CARING FOR ALUMINUM FRY PANS AND BOILING POTS It is not necessary to season aluminum pots before cooking with them. Wash with a liquid dish washing detergent and towel dry. After cooking, wash aluminum pots and fry pans in hot, sudsy detergent. If grease or black soot has cooked to the outside of the pot while cooking with your outdoor cooker, scrub the outside of the pot with a steel wool scouring pad.

  • Page 22: Section Iii - Recipes

    We have provided a few recipes below to get you started. There are a wide variety of seasonings/marinades available to experiment with and enjoy. Always wear protective oven mitts when handling and use caution. Follow all instructions in the King Kooker Instruction Manual when using your griddle. ®...

  • Page 23: King Kooker ® Vegetables

    The King Kooker Way! ® For a 22 quart pot, fill 1/2 full of water. Add 1 to 2, 16 ounce King Kooker Complete Crab Shrimp, ® Crawfish Boil (complete, nothing to add). Bring water to a rolling boil. Add seafood.

  • Page 24: Blackened Fish

    Blackened Fish Heat a cast iron skillet for at least ten minutes on your King Kooker ® Allow the skillet to get almost white hot -- hot enough to see the “flame circle” in the center of the skillet. This recipe produces lots of smoke.

  • Page 25: King Kooker ® Jambalaya

    Cut, wash and drain chicken pieces. Dip pieces into a mixture of beaten egg and milk. Coat with King Kooker® Seasoned Fish Fry. Heat oil to 350°F (177°C). Place chicken into oil and cook until done. Cooking outdoors with a large skillet allows for larger quantities to be prepared in less time.

  • Page 26: Fried Onion Rings

    (Make sure to never allow all of the steaming liquid to evaporate. A hole will be burned into the bottom of an empty pot on a lit cooker.) We recommend King Kooker® Complete Crab, Shrimp, Crawfish Boil to add flavor to all your steamed seafoods and vegetables.

  • Page 27: Section Iv - Frequently Asked Questions

    SECTION IV READ AND UNDERSTAND ALL INSTRUCTIONS BEFORE USING YOUR KING KOOKER ® PRODUCT FREQUENTLY ASKED QUESTIONS AND ANSWERS What is the problem if the cooker takes too long or will not heat oil or cooking ingredients to desired temperature? My cooker’s flame appearance is very weak.
  • Page 28 KING GRILLERDINE ® , KING KOOKER ® , the KING KOOKER ® logo, THE KING ® THE KING OF OUTDOOR COOKING ® , MR. OUTDOORS ® , and WATCHDOG OUTDOOR COOKER SERIES ®...
