King Kooker C90NG Assembly Instructions And Use And Care Manual

Outdoor cookers natural gas jet burners
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
English
ASSEMBLY INSTRUCTIONS
AND USE AND CARE MANUAL
THE INSTRUCTION MANUAL CONTAINS IMPORTANT INFORMATION
NECESSARY FOR THE PROPER ASSEMBLY AND SAFE USE OF THE APPLIANCE.
READ AND FOLLOW ALL WARNINGS AND INSTRUCTIONS BEFORE
ASSEMBLING AND USING THE APPLIANCE. FOLLOW ALL WARNINGS AND
7:30 AM to 3:30 P.M. CST • Monday through Friday
AND WARNINGS COULD RESULT IN FIRE, EXPLOSION, BURN HAZARD OR
CARBON MONOXIDE POISONING WHICH COULD CAUSE PROPERTY DAMAGE,
OUTDOOR COOKERS
NATURAL GAS
JET BURNERS
MODEL/SERIAL #
INSTRUCTIONS WHEN USING THE APPLIANCE.
KEEP THIS MANUAL FOR FUTURE REFERENCE.
METAL FUSION, INC.
712 St. George Avenue.
Jefferson, LA 70121
If you have any problems or questions
Call Us Toll Free at
1-800-783-3885
(504) 736-0201
www.kingkooker.com
FAILURE TO FOLLOW THESE INSTRUCTIONS
PERSONAL INJURY OR DEATH.
__________

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the C90NG and is the answer not in the manual?

Questions and answers

Related Manuals for King Kooker C90NG

Summary of Contents for King Kooker C90NG

  • Page 1 English OUTDOOR COOKERS NATURAL GAS JET BURNERS ASSEMBLY INSTRUCTIONS AND USE AND CARE MANUAL __________ MODEL/SERIAL # THE INSTRUCTION MANUAL CONTAINS IMPORTANT INFORMATION NECESSARY FOR THE PROPER ASSEMBLY AND SAFE USE OF THE APPLIANCE. READ AND FOLLOW ALL WARNINGS AND INSTRUCTIONS BEFORE ASSEMBLING AND USING THE APPLIANCE.

  • Page 2: Warnings

    DANGER FOR YOUR SAFETY If you smell gas: 1. Shut off gas to the appliance. 2. Extinguish any open flame. 3. If odor continues, keep away from the appliance and immediately call your Fire Department. FAILURE TO FOLLOW THESE INSTRUCTIONS COULD RESULT IN FIRE OR EXPLOSION WHICH COULD CAUSE PROPERTY DAMAGE, PERSONAL INJURY OR DEATH.
  • Page 3 READ AND UNDERSTAND BEFORE USING THIS PRODUCT Throughout this manual the words appliance, cooker, fryer/boiler, burner and stove will be used interchangeably to refer to the King Kooker Outdoor Cooker. ® This is an ATTENDED appliance. Do NOT leave this appliance unattended while the burner is lit or while heating oil, grease, water or cooking food.
  • Page 4 If the supply pressure is different than 7 inch water column, contact a licensed or certified plumber for assistance. 22) This appliance is not intended for commercial use. 23) Use King Kooker appliances only in accordance with state and local ®...

  • Page 5: Table Of Contents

    READ AND UNDERSTAND ALL INSTRUCTIONS BEFORE USING YOUR KING KOOKER ® PRODUCT TABLE OF CONTENTS Warnings ..................... . . 2-4 Table of Contents .

  • Page 6: Warranty

    METAL FUSION, INC. LIMITED ONE-YEAR WARRANTY WHAT THIS WARRANTY COVERS This warranty covers all components of this outdoor cooker to be free from defects in materials and workmanship, with the exceptions stated below. HOW LONG COVERAGE LASTS This warranty runs for one year from the date of purchase. Please keep your receipt with this manual for future reference.

  • Page 7: Owner's Registration

    OWNER’S REGISTRATION Dear Customer, Thank you for purchasing a King Kooker ! Please take a moment to fill ® out your registration form and return it to us. We are always happy to hear suggestions and comments from our customers about our products. Completion of this registration allows us to contact you if the need arises.
  • Page 8 TAPE HERE FOLD ________________________ ________________________ Place Stamp ________________________ Here METAL FUSION, INC. 712 St. George Avenue Jefferson, LA 70121 FOLD...

  • Page 9: Section I - Outdoor Cooker Assembly

    THE USE AND CARE MANUAL MUST BE READ AND UNDERSTOOD BEFORE USING THE APPLIANCE Throughout this manual the words appliance, cooker, fryer/boiler, burner and stove will be used interchangeably to refer to the King Kooker Outdoor Cooker. ® TOOLS REQUIRED: TORQUE WRENCH or ADJUSTABLE WRENCH, LEAK TESTING SOLUTION Before assembling, check that all cooker components are included in the shipping carton.

  • Page 10: Hose Assembly Instructions

    HOSE ASSEMBLY INSTRUCTIONS 1. Locate the appliance end (3/8 female flare swivel) of the hose. Wrench tighten the appliance end (3/8 female flare swivel) of the hose onto the brass adapter which is attached to the appliance valve. See below Figure 1. FIGURE 1 * Model May Vary From Picture APPLIANCE...

  • Page 11: Section Ii - Use And Care

    212 F(100 C). The temperature of hot oil should never be allowed to exceed ° ° F(177 IMPORTANT: Oil can ignite at high temperatures. Most King Kooker ® thermometers have a Red Zone above ° ° ° ° F(177 C) to signify Danger.

  • Page 12: Connecting Your Appliance To The Natural Gas Supply

    CONNECTING YOUR APPLIANCE TO THE NATURAL GAS SUPPLY 1. Use King Kooker ® appliances only in accordance with state and local ordinances, or in the absence of local codes, with the National Fuel Gas Code, ANSIZ223.1/NFPA 54 or CSA B149.1, Natural Gas and Propane Installation Code.
  • Page 13 8. Remove the protective plugs from the quick disconnect socket and unattached end (male) of the gas hose. Pull back the sleeve on the quick disconnect socket and insert the unattached end (male) of the gas hose into the socket. See Figure 3 below. Release the sleeve and continue pushing the hose into the socket until the sleeve snaps into the locked position.

  • Page 14: Leak Test Instructions

    LEAK TEST INSTRUCTIONS Before lighting the appliance, a thorough leak test must be satisfactorily completed using a non-ammonia soapy water solution (50% non-ammonia soap and 50% water). This is to be applied with a small brush to all gas joints (quick disconnect socket to gas supply piping assembly, appliance hose to quick disconnect socket assembly, appliance hose to the brass adapter assembly and the brass adapter to appliance valve assembly) after the appliance hose is inserted into the quick disconnect socket.

  • Page 15: Placement Instructions

    PLACEMENT INSTRUCTIONS 1. Never operate this appliance within 10ft. (3.05m) of any structure, combustible material or gas cylinder. Never operate this appliance within 25ft. (7.5m) of any flammable liquids or vapors 2. There must be no combustibles or roof overhead. 3.

  • Page 16: Lighting And Operating Instructions

    LIGHTING AND OPERATING INSTRUCTIONS THE COOKER MUST NOT BE LIT UNTIL THE PRECEDING PLACEMENT INSTRUCTIONS HAVE BEEN COMPLETELY FOLLOWED. Before lighting the cooker, check that the jet pipes and orifices are free from obstruction. The orifices should be positioned pointing up directly through the pipes as per Figure 1. Both situations must be corrected if necessary before lighting to prevent flashback.
  • Page 17 FIGURE 2 APPLIANCE VALVE “OFF” FIGURE 3 SHUT-OFF VALVE TURN TO “ON” POSITION. APPLIANCE HOSE APPLIANCE GAS SUPPLY QUICK DISCONNECT HOSE PIPING SOCKET SHUT-OFF VALVE GAS SUPPLY “OFF” PIPING FIGURE 4 FIGURE 5 APPLIANCE VALVE “ON” PIPE APPLIANCE NIPPLE HOSE FIGURE 6 NEVER PUT HANDS OR FACE DIRECTLY OVER BURNER WHILE LIGHTING OR WHILE THE APPLIANCE IS LIT.

  • Page 18: Turning Off And Storing The Cooker After Use

    F(38 C)]. ® After each use turn OFF the King Kooker at the appliance valve first, then at the gas shutoff valve at the gas supply. Check to make sure there is no flame and all valves are off. The gas must be turned OFF at the natural gas supply by closing the gas supply shutoff valve and removing the appliance hose from the quick disconnect socket when the appliance is not in use.

  • Page 19: Caring For Aluminum And Cast Iron Cookware

    TIPS FOR CARING FOR ALUMINUM FRY PANS AND BOILING POTS It is not necessary to season aluminum pots before cooking with them. Wash with a liquid dish washing detergent and towel dry. After cooking, wash aluminum pots and fry pans in hot, sudsy detergent. If grease or black soot has cooked to the outside of the pot while cooking with your outdoor cooker, scrub the outside of the pot with a steel wool scouring pad.

  • Page 20: Section Iii - Recipes

    Blackened Fish Heat a cast iron skillet for at least ten minutes on your King Kooker ® . Allow the skillet to get almost white hot -- hot enough to see the “flame circle” in the center of the skillet. This recipe produces lots of smoke.

  • Page 21: Section Iv - Frequently Asked Questions And Answers

    ANSWER: WE RECOMEND THAT THIS INSTALLATION BE DONE BY A LICENSED OR CERTIFIED PLUMBER. Keep this manual for furture reference. Use King Kooker ® appliances only in accordance with state and local ordinances, or in the absence of local codes, with the National Fuel Gas Code, ANSIZ223.1/NFPA 54, or CSA B149.1, Natural Gas and Propane Installation Code.
  • Page 22 NOTES...
  • Page 23 NOTES...
  • Page 24 KING GRILLERDINE ® , KING KOOKER ® , the KING KOOKER ® logo, THE KING ® THE KING OF OUTDOOR COOKING ® , MR. OUTDOORS ®...
