Page 1: Installation Instructions
HBS 200 HBS 300 HBS-DC HBS-DC HBS 300 HBS 200 English Installation Instructions Wireless High Bay Controls RoHS Compliant... -
Page 2: Package Contents
WARNING Autani HBS-DC Wireless System • Turn power off at the circuit breaker before installing the sensor • Sensor must be installed and used in accordance with appropriate electrical codes Autani wireless lighting control devices work and regulations together to create groups (or control zones) • Installation by a qualified electrician is recommended without the need for additional wiring. The devices are RF based, operating at a frequency of 2.4 GHz. Package Contents • HBS 200 or HBS 300 Autani HBS-DC Wireless System Specifications • HBS-DC Communication 2.4 GHz • Two 1/2” KO locknuts Frequency • Installation instructions Transmission Range 600 ft (182.8 m) depending on line of sight. Range may be less • HBS-DC Radio Module if signal needs to pass through obstacles. Installation Overview Needed for installation Intended uses... - Page 3 Product Overview HBS 300 with installed HBS-DC Product Overview HBS 200 with installed HBS-DC 120/ 120/ Fixture Fixture 230/ 230/ Aisle or J Box or J Box IP20 IP20 277 VAC 277 VAC Mount Mount Wireless Wireless 50/60Hz 360° 50/60Hz...
-
Page 4: Installation
Product Overview HBS-DC Installation The HBS-DC typically is factory pre- installed to a wireless control device. If installation is necessary, the module just 2.4 GHz Wireless snaps into the connection terminal. No tools are required. Product description The HBS-DC Wireless Control Module are controlled via autaniNet, providing works with STEINEL’s HBS 200 and HBS wireless fixture control on an individual or 300 wireless lighting control devices to group basis. Through Autani’s easy-to-use create control zones without the need for EnergyCenter interface, users can choose additional wiring. how individual fixtures or groups will Setup & Commissioning behave based on changes in schedule and The HBS-DC typically comes preinstalled occupancy. Users can easily modify fixture This sensor is commissioned remotely in the STEINEL wireless device. Devices behavior and how lights are grouped. through the EnergyCenter software. Specifications Communication frequency 2.4 GHz Operating temperature -4°F to +122°F; -20° C to +50°C Dimensions 2.96 x 1.38 x .62 in (75.2 x 35.05 x 15.75 mm) - Page 5 Mounting Mounting (continued) Placement guidelines - HBS 300, HBS 200 Junction box mounting - HBS 300, HBS 200 • Sensor module mounts to a 1/2” knockout of a lighting fixture or If mounting to the end of a fixture is not Junction junction box. possible, the HBS 300, HBS 200 can be • Detection lens must have a clear, mounted to any junction box with a 1/2” unobstructed view of controlled area (trade size) knockout. With the HBS 300 and must project beyond the lamps. and HBS 200, this may be necessary if the fixture location has an obstruction • Sensor should be 6 to 8 feet away from that would block the view of the sensor heating/cooling supply ducts. (for example: racking is directly beneath • Ideal mounting height is up to 45 feet. the fixture). HBS 300, HBS 200 • Must be mounted on a stable platform.
- Page 6 Setup & Commissioning – Without HBS-DC Installed Setup & Commissioning – With HBS-DC Installed Light level - HBS 300, HBS 200 Light level teach mode - HBS 300, HBS 200 See Autani Manager documentation. The light level feature allows lighting to The light level teach mode reads the remain OFF during daylight, regardless of ambient light level in the space and selects occupancy. Daytime operation is at 200...
- Page 7 LC5 180° half moon lens LC4 reduced range lens by pressing the tabs on either side of the cover for HBS 300 cover for HBS 300 sensor. Coverage may vary depending on mounting height and environmental conditions. 50 ft 53 ft radial tangential LC1 aisle starter cover for HBS 200 www.autani.com www.autani.com...
-
Page 8: Troubleshooting
Troubleshooting Warranty HBS-DC HBS 200, HBS 300 HBS 300, HBS 200 sensor troubleshooting Autani warrants that Autani Products STEINEL America warrants its products against defects in material or workmanship will be free from defects in materials Malfunction Cause Remedy for a period of five years. STEINEL will and workmanship and conform to its No power at the reset breaker, turn light switch breaker has tripped; light switch is in replace or repair the item provided that Specifications for a specified, fixed period sensor to ON position, check wiring OFF position it has not been altered or subjected to commencing on its date of shipment with voltage tester abuse, accident, improper installation or and continuing for five (5) years, except check for proper wiring short circuit improper use. There are no obligations the fixed period for Autani Software, connections Managers, and any Autani Product not or liabilities on the part of STEINEL for consequential damages arising out of or installed and commissioned by Autani or Lights do not switch... - Page 9 STEINEL America Inc. Autani, LLC 9O51 Lyndale Avenue South 7090 Columbia Gateway Drive USA - Bloomington, MN 55420 Suite 140 Tel: +1-952-888-5950 Columbia, MD 21046 Fax: +1-952-888-5132 Tel: +1-443-320-2233 www.steinel.net www.autani.com...
