  • Page 1 Operating Instructions A2000 3-348-981-03 Multifunctional Power Meter 29/5.18...

  • Page 2: Table Of Contents

    Instrument Description ......................4 Instrument Overview ............................4 Inputs, Outputs and Interfaces ..........................5 Available Measurement Data ...........................8 Possible A2000 Parameter Settings .......................10 Factory Default Instrument Parameters ......................12 Operating the A2000 ........................ 13 Control Panel ..............................13 Response After Auxiliary Power is Switched On ....................13 Menu Display for Measurements in 4-Wire Systems ..................14...
  • Page 3 Contents Page Dimensional Drawing .......................46 Technical Data ..........................47 Maintenance – Device Return and Environmentally Sound Disposal ........50 Repair and Replacement Parts Service Calibration Center and Rental Instrument Service ..............51 Product Support Industrial Division ...................51 GMC-I Messtechnik GmbH...

  • Page 4: Application

    Transformation ratios can be entered to the instrument, which means that all primary measurement data can be displayed directly at the A2000. Maximum values are stored to memory for every measured or cal- culated quantity. If limit values are exceeded, corrective action can be triggered via relay outputs. Energy meters, recorders, data loggers and control loops can be connected to the digital and analog outputs.

  • Page 5: Inputs, Outputs And Interfaces

    Inputs, Outputs and Interfaces Current Inputs All current inputs are isolated from one another. If measurements are performed with external trans- formers, their primary and secondary current values must be entered, in order to enable direct display of current values. Switching between the two meas. ranges (1 A and 5 A) is accomplished via software. Connection with 3 current transformers Connection with 2 current transformers in 3/4-wire systems (4L)
  • Page 6 Connection with 1 current transformer Connection with 3 current transformers in 3-wire systems (balanced load) (3L13) in 4-wire systems (Open Y) (4L13) 1 3 4 6 7 9 11 2 RELAY 1 RELAY 2 Power RELAY 1 RELAY 2 Power supply supply For this connection type the accuracy...
  • Page 7 LON model due to space limitations. The RS232 interface allows for the transmission of measurement values from the A2000 to a PC, as well as external instrument configuration. The chapter entitled “Interface Description” on page 44 provides detailed information regarding the generation of user specific programs.

  • Page 8: Available Measurement Data

    Available Measurement Data Individual Phases Collective Values Phase Voltages U1 ... U3 ... U3   max Delta Voltages U12, U23, U31 ... U31 avg avg max Phase Current I1 ... I3 ... I3   max Averaged Phase Current ...
  • Page 9 Display of Reactive Power DIN = calculation of reactive power per Sign = calculation of reactive power with + or – DIN 40110 without + or – sign S 2 P 2  –   dt   – t ...

  • Page 10: Possible A2000 Parameter Settings

    Possible A2000 Parameter Settings Transformer  Transformer  Inputs Primary Transformer Secondary Trans- Synchronization Pulse 4 or 3-Wire Phase Conductor former Phase Conduc- Primary Current Secondary Current Connection external or internal:  100 V ... 800 kV 100 V ... 500 V 1 A ...
  • Page 11 Possible Parameter Setting, Data Logger Trigger: relay 1, Relay 2, both, off Pretrigger: 0%, 25%, 50%, 75% Disable Trigger: External (Synchronizing Input), off Sampling  Storetime: 1 min, 2 min, 5 min, 10 min, Storemode: cyclic, once Time: 0,3 s, 0,6 s, 1 s, 2 s, 5 s, 10 s, 15 min, 30 min, 1 h, 2 h, 4 h, 15 s, 30 s, 1 min, 2 min, 5 min,...

  • Page 12: Factory Default Instrument Parameters

    Factory Default Instrument Parameters Transformer  Transformer  Inputs Primary Transformer Secondary Transformer Synchronization Phase Conductor Phase Conductor Primary Current Secondary Current Pulse 4-Wire 500 V 500 V Internal, 15 minutes Source Limit Value Contact Type Hysteresis, Delay Alarm Memory Relay 1 Relay 2 240 V...

  • Page 13: Operating The A2000

    Operating the A2000 Control Panel 8888 L1L2L3 T1: select phase L1, L2, L3 and/or measuring input In1, In2 MkVArWh 8888 8888 T2: selection of measured quantities: voltage, current, power, energy,... MkVArWh MkVArWhHz T3: max: Max. value display for desired quantities...

  • Page 14: Menu Display For Measurements In 4-Wire Systems

    Menu Display for Measurements in 4-Wire Systems   1 Only in energy meter mode, individual phases (L123) See diagram L1 for L2 values See diagram L1 for L3 values Pint Qint Sint P P Q Q S Int Int Int P...
  • Page 15 If a rotating field is estab- L1 L2 L3 continued from page 14 bottom lished at the U or I inputs of the A2000, the neutral con- for Feature A3 only (Analog Input) ductor current is displayed instead of the frequency.

  • Page 16: Menu Display For Measurements In 3-Wire Systems

     LT– HT– L1 L2 L3 If a rotating field is established at the U or I inputs of the A2000, the neutral conductor current is displayed instead of the frequency. When displaying the maximum values of I1 h the harmonic, press key...
  • Page 17 Pint Qint Sint Q Int Int Int ..... Q  LT– : select intervals -n * display interval (n = 0 ... 10) 0 = current interval in use  with projected final value HT– The maximum value since the last deletion or after restarting the instrument is displayed with the max setting (with T3).

  • Page 18: Error Messages

    One or more parameters have Check the measuring volt- The calibration values of been irretrievably corrupted or ages with a multimeter in the the A2000 are beyond the are beyond the setting range. direct current measuring setting range or are not config-...

  • Page 19: Configuring The A2000

    Configuring the A2000 Configuration changes are only possible if the ’LOCK’ DIP switch is in the ’off’ position. Sub-Menus Configurations Menu Limit value monitor. long see chap. 4.1, page 20 Min-/Max active Relays source, hysteresis Time alarm memory 2 Minutes Brightness and see chap.

  • Page 20: Configuring The Limit Value Relays

    Configuring the Limit Value Relays p r o g Menu long Display r e l a Display Menu ... Time 2minutes brief brief storage to memory no storage to memory Continue for intervalic with relay 2 Source L1 power storage to memory r e l 1 r e l 1 r e l 1...
  • Page 21 Example: Limit value relay 2, but with other quantities and values. r e l r e l 1 r e l 2   c h a n e delay 40 s : Value setting on/dip disables changes  Relay 2 Relay 1...

  • Page 22: Adjustment Of Display Brightness And Filter

    Adjustment of Display Brightness and Filter Adjusting display brightness p r o g Menu long Display disp Measuring Inputs Menu... Time 2 minutes brief brief storage to memory no storage to memory Adjusting display filter disp filt Parameters for display brightness The values are adopted : Adjustment of values immediately upon entry.
  • Page 23 Parameters for display filter : Adjustment of values Time constant  in s 0 ... 30 no filter effect 30 maximum filter effect The display filter is a software filter which acts as Set the time constant to 0, if the changes are to a lowpass function with the time constant .

  • Page 24: Measurement Inputs, Configuring The Synchronizing Input

    Measurement Inputs, Configuring the Synchronizing Input p r o g Menu long Display in p u Analog Output Menu ... Time 2minutes brief brief storage to memory no storage to memory 3-Wire Connection storage to memory in p u in p u in p u in p u l in e...
  • Page 25 in p u in p u in p u in p u s ec s y n c r o n freq ency 1.000 15 m auto Input transformer Input transformer Synchronizing pulse Line frequency adjustment  secondary current: 1.00 A every 15 minutes synchronization current transformer...

  • Page 26: Messeingänge, Analogeingänge Konfigurieren (Feature A3) (Nicht Bei Lon Und Profibus-Dp)

    Configuring the Measuring Inputs, Analog Inputs (feature A3) (not with LON and Profibus-DP) p r o g Menu long Display Analog Input Menu ... Time 2minutes brief brief storage to memory no storage to memory storage to memory standard range range point 4-20...
  • Page 27 in 2 in 2 in 2 in 2 pt1000 point 0ffset °C °C pt1k Analog input 2  Analog input 2  Analog input 2 Input signal Display dimension Display resolution for analog input 2 Correction of measuring error by cable resistance : Value Settings : Value Settings : Type Settings...

  • Page 28: Configuring The Analog Outputs (Not With Profibus-Dp)

    Configuring the Analog Outputs (not with Profibus-DP) p r o g Menu long Display a n a o u t Pulse Menu ... Time 2minutes brief brief storage to memory no storage to memory Continue with for intervalic analog output 2 power Source storage to memory...

  • Page 29: Configuring The S0 Pulse Outputs

    Configuring the S0 Pulse Outputs p r o g Menu long Display p u l s Interface Menu ... Time 2minutes brief brief storage to memory no storage to memory Source for pulse output 1 storage to memory p u l s p u l s p u l s p u l s...

  • Page 30: Data Logger Display And Configuration

    Data Logger Display and Configuration Display for Trigger Source Setting rel 1, rel 2, both Rotating points  Maximum number p r o g indicate that data  of storable trigger is being stored to events (N) L . o ..G . G . r 10 memory.
  • Page 31 53 o o 0 ... 99 %, FULL (memory occupancy level) If the power supply is interrupted during a recording session, the A2000 supplements the outstanding samples after restarting the instrument: • A value of „0“ is entered for all measured quantities, except for energies (last meter reading) •...
  • Page 32 p r o g Menu long Display L o G G Energy meter menu ... Time 2minutes brief brief storage to memory no storage to memory storage to memory l o G T r iG pre t rig di5 t r ig start 50 o o rel 1...
  • Page 33 samp l time stor e time 0. 3 5 Sampling time Storage rate 0. 3 5 30 m Sec: 0.3, 0.6, 1, 2, Min: 1, 2, 5,10, 15, 30 hour:1, 2, 4, 8, 12 5,10, 15, 30 Min: 1, 2, 5, 10, 15, 30 day: 1, 2, 4 Sampling time T , storage time T...
  • Page 34 storage to memory Source selection t rac e 12 stor e mode t r a c e see T1 below Measuring quantity gYgl selection see T2 below Memory is overwritten  Selection of max. 12 quantities  to be recorded cyclically when full.

  • Page 35: Configuring The Energy Meter Mode/Low Tariff

    Configuring the Energy Meter Mode/Low Tariff p r o g Menu long Display e n E R G Y Interface Menu ... Time 2minutes brief brief storage to memory no storage to memory Only appears for data logger,  LON or Profibus variant storage to memory e N E R e N E R...

  • Page 36: Interface Configuration

    Interface Configuration p r o g Menu long Display c o m Standard Parameters Menu ... Time 2minutes brief brief storage to memory no storage to memory storage to memory c o m c o m1 c o m1 c o m1 a dr e b au d a t e...
  • Page 37 Only appears for LON interface variant: Only appears for Profibus DP variant: storage to memory c o m2 L o n c o m2 L o n 00c0 0015 pro F StAt SEnd 6800 WcFG LON service, only if LON ID: 00c000156800 Status: Wait Config key is pressed and held...

  • Page 38: 4.10 Uploading And Deleting Parameters, Setting The Clock

    4.10 Uploading and Deleting Parameters, Setting the Clock p r o g Menu long Display s e t Relay Menu ... Time 2minutes brief brief storage to memory no storage to memory storage to memory s e t s e t s e t s e t d e f a l t...
  • Page 39 Only appears for data logger,  LON or Profibus variant storage to memory s e t s e t s e t 14. 1 0 1998 r E A c t P 14. 2 8 0 8 date time Selection: with or  Selection and storage of Selection and storage without + or - sign...

  • Page 40: Electrical Connections And Circuits

    Electrical Connections and Circuits Design with 2 or 4 analog outputs and serial interface RS-232 and RS-485 or LON 13 14 15  N 115V 230V ±10% 45...65 Hz 20...69 V  Relay 1 Relay 2 Power supply N L1 L2 L3 (see specified 20...72 V values on ...
  • Page 41 Design with 2 analog inputs and 2 outputs and serial interface RS-232 and RS-485 13 14 15  N 115V 230V ±10% 45...65 Hz Relay 1 Relay 2 N L1 L2 L3 20...69 V Power supply (see specified 20...72 V values on ...
  • Page 42 RS-232 Pin Assignments RS-485 Pin Assignments (not included with LON variant) Sub-D plug at PC A2000 Master A2000 Master No. of pins 25 9 RS-232 ------- ------- ------- Matching ------------ TxD ------- ------- ------- resistor ------------ RxD ------- ------- ------- 20 4 ------------ ...
  • Page 43 Profibus DP connection (optional) 13 14 15  N 115V 230V ±10% 45...65 Hz 20...69 V  Power supply (see specified 20...72 V values on  73...264 V  serial plate) 73...276 V 20... 27 V 20... 36 V Relay 1 Relay 2 N L1 L2 L3 Power supply ...

  • Page 44: Interface Description

    Electrically Isolated Circuits Voltage Limit Value Relay 1 Inputs Limit Value Relay 2 Pulse Outputs Current S01, S02 (optional) Inputs common reference point + Analog Outputs Synchronizing A1, A2, (A3, A4 optional) Input Analog inputs  (Option In1, In2 )  Power Supply ...

  • Page 45: General

    The communications protocol in accordance with DIN draft 19244, EN 60870 or the Modbus protocol is used for communications between the field control and device levels. The A2000 utilizes only a sub- set of the functions defined in the protocol. Separate descriptions are available for each of the individual communications protocols.

  • Page 46: Dimensional Drawing

    Dimensional Drawing 2 ... 25.4 151.1 59.1 Panel Cutout 138 x 138 All dimensions in mm GMC-I Messtechnik GmbH...

  • Page 47: Technical Data

    Technical Data Analog Inputs Measurement Inputs MR = Measuring Range Voltage Inputs Standard signal:  Phase – Phase 0 ... 500 ... 550 V, – Standard (20 mA: 4 ... 20 mA,  40 ... 70 Hz 0 ... 20 mA, 20 mA,  Phase –...
  • Page 48 – Display Values Pulse Outputs for Standard Signal Lower/Upper Range Limit – 1999 ... + 9999  Contact open collector Current 10 mA ... 27 mA configurable OFF < 2 mA Resolution depending on range and External Voltage 8 ... 30 V position of decimal point Pulse Duration selectable 100 ...
  • Page 49 Display Electrical Safety Type 7-Segment LED Variants IEC 61010-1 / EN 61010-1 Display Color Protection Class Character Height 13.2 mm Measuring Category inputs: III, relays: II Display Range Contamination Level Energy 999999999 Operating Voltage 300 V Power Factor 1.00 Test Voltage measuring inputs: 3.7 kV Other Quantities 9999...

  • Page 50: Maintenance - Device Return And Environmentally Sound Disposal

    Note: Our repair service also performs instrument calibrations, if required. Device Return and Environmentally Sound Disposal The A2000 is a category 9 product (monitoring and control  instrument) in accordance with ElektroG (German electrical and electronic device law). This device is subject to the RoHS directive.

  • Page 51: Repair And Replacement Parts Service

    Repair and Replacement Parts Service Calibration Center and Rental Instrument Service When you need service, please contact: GMC-I Service GmbH Service-Center Beuthener Str. 41 90471 Nürnberg, Germany Phone +49 911 817718-0 +49 911 817718-253 E-mail service@gossenmetrawatt.com www.gmci-service.com This address is only valid in Germany.  Please contact our representatives or subsidiaries for service in other countries.
  • Page 52 Edited in Germany • Subject to change without notice • A pdf version is available on the internet Phone +49 911 8602-111 GMC-I Messtechnik GmbH +49 911 8602-777 Südwestpark 15 E-Mail info@gossenmetrawatt.com 90449 Nürnberg • Germany www.gossenmetrawatt.com...
