Dakota Micro DMAC-H9QC2 User Manual

Inc. 9" ahd quad monitor
Hide thumbs Also See for DMAC-H9QC2:
Table of Contents

Advertisement

Quick Links

*Kit shown without all components included in double camera kit
MORE
Rev: 10/03/18
Dakota Micro, Inc.
Users Manual
Dakota Micro, Inc. 9" AHD Quad Monitor
Part Number(s):
DM-H9Q / DMAC-H9QC2 / DMEC-H9QC2
Page 1 of 12

Table of Contents

A. Camera
IV.
V.
VI.
VII.
VIII.
IX.
X.
XI.
Monitor, Quad, & Remote Operation
A. Quad Monitor Operations - Front
XII.
Standard Monitor Menu Settings
A. Standard Monitor Menu Settings Navigation
XIII.
C. Quad Processor
XIV.
XV.
XVI.
XVII.
Disclaimer
XVIII.
2
3
3-4
4
4
4-5
5
5
6
6
6-7
8-9
10
11
12
12
12
12
Author: CNR

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DMAC-H9QC2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Dakota Micro DMAC-H9QC2

Summary of Contents for Dakota Micro DMAC-H9QC2

  • Page 1: Table Of Contents

    Dakota Micro, Inc. Users Manual Dakota Micro, Inc. 9” AHD Quad Monitor Part Number(s): DM-H9Q / DMAC-H9QC2 / DMEC-H9QC2 Table of Contents I. Included Monitor & Camera Kit Components II. Standard Features A. Cameras B. Monitors C. Cables III. Parts of an AgCam /EnduraCam A.

  • Page 2: Included Monitor & Camera Kit Components

    DM-H9Q User Manual Always read the manual prior to operating this equipment. Also, please follow all safety signs and precautions. See the Dakota Micro, Inc. website for installation training videos at www.dakotamicro.com. INCLUDED MONITOR KIT COMPONENTS INCLUDED CAMERA KIT COMPONENETS...

  • Page 3: Standard Features

    This lens is also transparent of infrared light, allowing the LED’s to penetrate even when it is darkened  Solid billeted aluminum camera body featured Dakota Micro’s proprietary triple o-ring seal making the 100% waterproof even under direct high pressure spray and underwater use ...

  • Page 4: Parts Of An Agcam /Enduracam

    DM-H9Q User Manual  Over the course of 2018, all Dakota Micro monitors will be transitioned to AHD (Analog High Definition). Both Legacy (Analog) AgCam and EnduraCam cameras and AHD AgCam and EnduraCam cameras will function perfectly on the new Dakota Micro AHD Monitors.

  • Page 5: Cable Routing Tips & Warnings

    WARNING: Dakota Micro, Inc. is not responsible for any damages caused to your monitor, or yourself, due to the improper installation or use of a suction cup monitor mount, whether it be product sold by DM or product purchased from another source.

  • Page 6: Power

    If you would like to hardwire your power supply, please contact your local AgCam® dealer for available hardwire power adaptors (PN: DMAC-HARDWIRE). 2. Dakota Micro hardwire power adaptors have a maximum circuit capability of 5 amp. C. Fuses 1. There is a small in-line glass fuse located on the red and black power wire (3 above). When replacing this fuse, use a MAX 2amp glass fuse.

  • Page 7: Remote Operations

    Dakota Micro, Inc. DM-H9Q User Manual Full Screen Will show cameras 1/2/3/4 each time pressed. Duplex Will show cameras 1/2 and cameras 3/4 each time pressed. Screen First press will display all four (4) cameras connected. Second press initiates auto. rotation Quad Screen between Quad screen/cam 1/cam 2/cam 3/cam 4.
  • Page 8 Dakota Micro, Inc. DM-H9Q User Manual XII. MONITOR MENU SETTINGS 1. Press the MENU key on the face of monitor or remote. Use the AV button to toggle between menu sections 2. Use – and + keys on the monitor or the LEFT and RIGHT arrow keys on the remote to move through the icons at the top of the screen.
  • Page 9 Dakota Micro, Inc. DM-H9Q User Manual SETTING MENU LANGUAGE: Adjusts menu language AHD1 TRIGGER DELAY: Turns ON/OFF Trigger Delay for Camera 1 AHD2 TRIGGER DELAY: Turns ON/OFF Trigger Delay for Camera 2 AHD3 TRIGGER DELAY: Turns ON/OFF Trigger Delay for Camera 3...

  • Page 10: Specifications

    Dakota Micro, Inc. DM-H9Q User Manual XIII. SPECIFICATIONS A. Camera Image Sensor 1 / 2.7” CMOS Sony 3 Way –Video System (NTSC or PAL), Video Output Type (AHD or Programmability CVBS/Analog), Forward or Mirrored Programmable at factory level only Video System NTSC (Silver body) / PAL (Black body) –...

  • Page 11: Warnings

    8659 148th Ave. SE Cayuga, ND 58013 6. Upon receipt and evaluation of product at Dakota Micro Factory, it will be established if the repair is warranty or non- warranty. If requested, customer will be called and notified of any applicable charges.

  • Page 12: Consumer Limited Warranty

    Any action at law, suit in equity, or other judicial proceeding for the enforcement of any right provided for herein or otherwise, or with respect to any claim that a purchaser may have against Dakota Micro shall be instituted only in the Courts of the State of North Dakota, either in the state district court located in Wahpeton, North Dakota or in Federal District Court location in Fargo, North Dakota.

This manual is also suitable for:

Dm-h9qDmec-h9qc2Dm-h7Dm-h9Dmac-h9c2Dmec-h7c1 ... Show all

Table of Contents
