Dakota Micro® AHD 9" Quad Monitor
Always read the manual prior to operating this equipment. Please follow all safety signs and precautions.
Included Components
Dakota Micro® AHD 9" Quad Monitor
Dakota Micro® AHD 9" Quad Monitor Wire Harness
PN: DM-H9QMWH
Dakota Micro® AHD 9" Quad Monitor Remote
PN: DM-H9QRMT
Dakota Micro® 9" Monitor Sun Shade
PN: DM-9SHADE
Dakota Micro® 9" Monitor U-bracket and Hardware
PN: DMAC-9M Bracket
Dakota Micro® 2.1 Barrel Male to Auxiliary Power
PN: DM-12V
AU: MES
User Manual DM-H9Q
BY: SJE
Rev: 04/23/25
1
