Paramount Fitness MDX2 Installation Manual

Anti-entrapment debri drain
Hide thumbs Also See for MDX2:

Advertisement

Quick Links

ONLY FOR POOLS
WITH AN EXISTING
MDX SUMP
Safety compliant according to the Virginia Graeme Baker Pool and Spa Safety Act
ANSI/APSP - 16 - 2011
Compliant with ANSI/APSP - 7 - 2006.
NOTICE
WARNING
295 East Corporate Place • Suite 100 • Chandler, AZ 85225
Phone: 0011 + 1 + 480.893.7607 • Fax: 0011 + 1 + 480.753.3397
Paramount@1Paramount.com • www.1Paramount.com
US and Foreign patents and patents pending see www.1paramount.com/about/patents/
004-027-8829-00
ECN_1298 REV08017
RETROFIT FIBERGLASS, VINYL & CONCRETE POOLS WITH MDX
SUBMERGED SUCTION OUTLET FOR MULTIPLE DRAIN USE FOR
USE ON FLOOR AS A REPLACEMENT FOR MDX DRAINS ONLY
To Installers: Read and follow these instructions. Give these instructions to the
facility owner to keep for future reference. Follow all codes and regulations that
apply to the design, installation and use of suction outlet fittings.
MDX2 must be installed in accordance with Paramount's written instruction
manual, and in conformity with applicable Federal, State, Local and Swimming
pool industry building and safety codes.
ANTI-ENTRAPM ENT DEBRIS DRAIN
MDX2 INSTALLATION MANUAL

Advertisement

loading
Need help?

Need help?

Do you have a question about the MDX2 and is the answer not in the manual?

Questions and answers

Summary of Contents for Paramount Fitness MDX2

  • Page 1 Follow all codes and regulations that apply to the design, installation and use of suction outlet fittings. MDX2 must be installed in accordance with Paramount’s written instruction WARNING manual, and in conformity with applicable Federal, State, Local and Swimming pool industry building and safety codes.
  • Page 2 Signal Words and Symbols Used In This Manual This Owner’s Manual and Installation Guide contains specifi c precautions and symbols to identify safety- related information. You will fi nd DANGER, CAUTION, WARNING and NOTICE symbols which require special attention. Please read them carefully and follow these precautions as indicated! They will explain how to avoid hazards that may endanger you or persons using or maintaining your pool or spa.
  • Page 3 MAINTENANCE INSTRUCTIONS & WARNINGS: WARNING DEATH or SERIOUS INJURY can result from pool or spa drain covers or grates that are clogged by debris. • All pool and spa drain covers may become obstructed by debris and should be cleaned periodically due to clogging from debris, such as pieces of plastic, hair, fabric, twigs, leaves, seeds, etc.
  • Page 4 Be sure to replace these covers with a SDX2 or SDX2 retro covers to bring all suction outlets into compliance. DO NOT INSTALL THE MDX2 RETRO UNLESS THERE IS AN MDX SUMP AVAILABLE TO ACCEPT THE MDX2 RETRO.
  • Page 5 3. Install the cover (#7) onto the upper support (#5) and secure with 6 (six) security screws (#8) and 2 (two) security screws (#9). Note: Anchor clips not used in Concrete 1 PC installation 004-202-2221-XX MDX2 RETRO FOR CONCRETE Replace within 05 installed years Item...
  • Page 6 MDX2 - CONCRETE DRAIN ASSEMBLY Concrete Drain Assembly (with leveling ring): After draining the pool: 1. Position the Retro Lower Support (001-250-2064-00) over the existing sump as shown in figure 1 and attach with the screws (6) and anchor clips (3) provided by Paramount. (Fig. 1) 2.
  • Page 7 Screw: No. 10X3/4” Security Head 005-252-2205-XX MDX2 Cover (XX=Color Code) Screw: No. 8X3/8” Security Head 005-202-2213-00 Screw: No. 10X3/4” Screw Pack MDX2 Retro (includes item #5,6,7,8,10,12,13,) * Not part of MDX² Retro For technical assistance call 1.800.621.5886 or contact your regional representative...
  • Page 8 Screw: 12-14 x 1 1/2” Vinyl Sump 005-252-2044-00 Seal Ring 005-252-0010-00 Vinyl Gaskets (2 pk) 005-202-2211-00 Screw Pack MDX2 Vinyl (includes item #s 2, 3, 6, 8, 9) * Not part of MDX² Retro For technical assistance call 1.800.621.5886 or contact your regional representative...
  • Page 9 Screw: 12-14 X 1 1/2” Vinyl/Fiberglass Sump (12 pk) 005-252-0816-00 Screw: 12-14 X 1” Vinyl/Fiberglass Sump (12 pk) Mounting Ring 005-252-0010-00 Gasket (2pk) 005-202-2212-00 Screw Pack MDX2 Fiber (Includes item #s 2,6,8,10,11) * Not part of MDX² Retro For technical assistance call 1.800.621.5886 or contact your regional representative...
  • Page 10 MDX-R3 WINTERIZATION WITH CANISTER If vacuum relief suction outlets are located below freeze line skip steps 1 and 2. 1. Remove grate from wall drain and install a 13-¾ blow through plug and blow line to achieve airlock. 2. If 3rd suction line is installed remove grate, install a 13-¾ blow-through plug and blow line to achieve airlock.
  • Page 11 For technical assistance call 1.800.621.5886 or contact your regional representative...
  • Page 12 For technical assistance call 1.800.621.5886 or contact your regional representative...
