Concepts Use & Care Manual
Operation: Mobile Hand Sink
The hand sink is to be used for hand washing only,
not for consumption.
Hot water heater MUST be filled with water before
connecting the water heater to power to prevent
damage to the heater.
The fresh water and waste water containers are located in the base
of the sink compartment on the right. The fresh water containers are
on the left with clear vinyl tubing and waste water tanks are on the
right with a rigid drain tube. Two fresh water and two waste water
containers are provided with each unit.
To add water to the fresh water container, remove the cap the vinyl
tubing is connected to on the container by pressing the button on the
cap and pull out the cap from the container. Pull the container out
of the sink base and unscrew the cap of the fill access hole at the
back of the container. Fill the container with water and screw the cap
back on at the back of the container and push the cap with the vinyl
tubing back into place at the front. Make sure there are no kinks in
the clear vinyl tubing.
Verify the black waste arm at the end of the drain line is in the hole
on the waste container.
Before Operating The Sink:
Water heater MUST be filled with water before connecting the water
heater to power to prevent damage to the heater.
Before plugging the sink into a wall receptacle, verify the water pump
only is plugged into the GFCI receptacle in the base of the unit. If the
water heater is plugged in, unplug it until the heater has been filled
with water. Put the switch and the breaker to the "ON" position in the
base of the unit. Make sure the GFCI receptacle is ON.
Operation: Tower Module
Verify the module is plugged into a receptacle and the Reach-In is
plugged into the GFCI receptacle. If lights were provided, turn on the
on /off switch on the back of the tower.
The flanged feet must be bolted to the floor.
12
For customer service, call (800) 733-8829, (800) 773-8821, Fax (989) 773-3210, www.delfield.com
To fill the water heater with water, turn on the hot water handle on the
faucet until water flows. When water flows into the sink, the water
heater is filled with water. The water heater can now be plugged
into the GFCI. Verify the water heater power switch on the front of
the heater is ON. The red light on the switch will stay on until it has
reached the set temperature.
Changing containers:
To switch out the waste water containers, get as much residual water
out of the drain into the container before removing. Lift the black
elbow out of the container and pull part of the drain line through the
hole in the compartment center divider to create an elbow in the
drain line to prevent water from draining out while switching out the
containers. When the empty container is in place, pull the drain line
back through the center divider and put the black elbow into the hole
in the container.
To prevent waste water overflow:
• Switch the fresh water and waste water containers at the same
time.
• Do not pour excess liquids into the sink
To adjust the water temperature, refer to the water heater
manufacturer's manual provided with the unit.
The hot water heater and the water pump is on a sliding shelf. Use
the handle provided in the shelf slide it out to access the heater and
other components.
The soap dispenser container is located in the base of the unit. The
container is threaded into the soap dispenser pump. Liquid soap
only is to be used in the soap dispenser.
