Delfield F14EW232 Specifications

Short Form Specifications
Exterior top is one-piece 16-gauge stainless steel, with integral 2.12"
(5.6cm) square nosing on front and 4" (10.1cm) high by 2.00" (5.1cm) thick
backsplash on rear. Interior sides are 22-gauge stainless steel.
Top to have 11.87"x 19.87" (30.2cm x 50.5cm) openings to hold pans (sup-
plied by others). Unit has (1) 16-gauge stainless steel tank with 1" (2.5cm)
drain with gate valve. Units 32", 48" or 60" in length have (1) 5 kw electric
immersion heater; 72" and 88" lengths have (2) 5 kw electric immersion
heaters located beneath openings. Heaters are standard at 240V, single
phase (*208V available upon request). Control to be mounted in front edge
of 8" (20.3cm) wide stainless steel plate shelf.
Manual fill faucet that extends 2.5" (6.4cm) above backsplash is standard.
Lower portion of unit to have 22-gauge stainless steel open shelf.
Electrical connections are 120/240V. Unit must be hard wired.
Unit is mounted on 6.13" (15.6cm) high adjustable stainless steel legs.
NOTE: Model F14EW hot food tables are designed to be operated with water
in the tank only. Use of the equipment without water in the tank will result in
damage to the equipment and will void the warranty.
Optional Accessories & Modifications
906A Stainless steel end
505B Stainless steel back
906E Laminate end
505A Laminate back
204C Auto fill assy (mechanical float)
204D Auto fill assy (electric probe)
1030A Cutting board (.5" x 10" composite)
108
Locks
726A Dry drawers — 19"
726B Dry drawers — 27"
726C Dry drawers —32"
216
*Three phase electrical system
*Inclusion of this option will alter the electrical specifications of
the unit.
The Delfield Company, 980 S. Isabella Rd., Mt. Pleasant, MI 48858, U.S.A. • (800) 733-8821 • Fax (800) 669-0619 • www.delfield.com
Delfield reserves the right to make changes in design or specifications without prior notice. ©2002 The Delfield Company. All rights reserved. Printed in U.S.A.
31.50" (80 cm) Deep Electric Hot Food Tables — Single Tank
PROJECT
ITEM #
QUANTITY
APPROVAL
Model F14EW232
Shown with optional cutting board
DATE
F14EW
