Display Address
This command can be used to place the cursor at any location. The corresponding
address for each character on the screen is as bellows:
Character
(addressing)
1
2
3
4
5
6
7
8
Character
(addressing)
1
2
3
4
5
6
7
8
4. scape Mode(0xFF):
Transmit one byte ASCII 0xFF to escape chars like "0xFB, 0xFC, 0xFD, 0xFE, 0xFF"
4
Line 1
Location Character
00 9
01 10
02 11
03 12
04 13
05 14
06 15
07 16
Line 2
Location Character
40 9
41 10
42 11
43 12
44 13
45 14
46 15
47 16
Location
(addressing)
08
09
0A
0B
0C
0D
0E
0F
Location
(addressing)
48
49
4A
4B
4C
4D
4E
4F
