DISMANTLING THE ENGINE

Refer to the 250 SE-R/300 SE-R spare parts catalogue for exploded views.

DRAINING THE GEARBOX

• Remove the drain plugs
oil drain.
REMOVING THE PINION AND
SELECTOR
• Unfold the safety washer's tab
punch.
• Remove the gearbox output pinion
• Remove the screw
selector.
• Remove the clutch control rod.
12
and , let the
using a
.
and extract the
250-300 SE-R
1
2
