- Page 1 Edition Geared Motors HW30, HS40, HS41, HK40, HS50, HS60 for Trolley Drive Systems 07/2000 Operating Instructions 1050 4214 / EN...
- Page 2 SEW-EURODRIVE...
-
Page 3: Table Of Contents
Installing the drive rod................8 Gear units with solid shafts ............... 8 Commissioning ....................10 Commissioning of gear units HW30 and helical-worm gear units HS..10 Inspection / Maintenance ................11 Inspection and maintenance intervals............. 11 Lubricant change intervals ..............11 Inspection and maintenance .............. -
Page 4: Important Notes
Important Notes Important Notes Warning Always follow the warnings and safety instructions in this publication! and Safety Instructions Electrical hazard Possible effects: Serious or fatal injury. Immediate danger Possible effects: Serious or fatal injury. Dangerous situation Possible effects: Minor injury. Harmful situation Possible effects: Damage to equipment or surroundings. -
Page 5: Safety Instructions
Safety Instructions Safety Instructions Preliminary The following safety instructions refer primarily to the operation of gear remarks units. When operating geared motors, please also observe safety instructions for motors in the corresponding operating instructions. Please refer to the additional safety instructions in the individual sections of these operating instructions. -
Page 6: Installation
® – with Spiroplan gear unit HW30 and helical-worm gear HS..: no large external mass moments of inertia are present that could exert a restoring load on the gear unit (with η’ (restoring) = 2 – 1/η < 0.5 self-locking) - Page 7 Installing the gear unit Use plastic inserts (2–3 mm thick) if there is a risk of electrochemical corrosion between the gear unit and the driven machine (connection between different metals such as cast iron and high-grade steel)! Also fit the bolts with plastic washers! Ground the housing additionally –...
-
Page 8: Assembly / Disassembly
DR.. Installing the drive rod ® Install the supplied drive rod (with Spiroplan gear unit HW30 and helical-worm gear unit HS40/41) into the operating lever and secure it with a lock nut. Gear units with solid shafts Mounting of... - Page 9 Gear units with solid shafts Figure 2 shows the correct mounting arrangement of a carrying wheel in order to avoid impermissible overhung loads. wheel hub wheel hub incorrect correct 03604AEN Figure 2: Correct mounting arrangement of a carrying wheel • Only use a mounting device (see Figure 1) for installing input and output elements.
-
Page 10: Commissioning
® Running-in The Spiroplan gear unit HW30 and the helical-worm gear unit HS.. require a running- period in period of at least 24 hours before reaching their maximm efficiency. A separate running-in period for each direction of rotation is required if the gear unit is operated in both directions of rotation. -
Page 11: Inspection / Maintenance
(→ Figure 3) at least every 5 years Renew the anti-friction bearing ® Spiroplan gear units HW30 are lubricated for life and, therefore, are maintenance-free. Table 2: Inspection and maintenance intervals Lubricant change intervals 30000 Average value per type of lubricant at 70° C... -
Page 12: Inspection And Maintenance
Inspection and maintenance Inspection and maintenance Do not mix synthetic lubricants with each other and do not mix synthetic and mineral lubricants! Oil is the standard lubricant. The location of the oil level plug, the oil drain plug and the breather plug for the different mounting positions can be found in the corresponding figures (see section 8.1). -
Page 13: Operation And Service
Gear unit malfunction Operation and Service Please provide the following information if you require assistance from our customer service department: • Nameplate data (complete) • State type and extent of the fault • Time and circumstances of the fault • Presumed cause Gear unit malfunction Malfunction... -
Page 14: Mounting Positions
General information on mounting positions Mounting positions General information on mounting positions Mounting SEW distinguishes the four mounting positions M1 – M4 with right-angle geared motors position for trolley drive systems. The following figure shows the spatial position of the gear unit designation with mounting positions M1 –... -
Page 15: Hw30 D
HW30 D.. 06 007 000 HW30 D.. 270° Normal 0° 180° Normal Normal Normal 90° Gear Units for Trolley Drive Systems - Operating Instructions... -
Page 16: Hs40 D
HS40 D.., HS41 D.. 06 008 000 HS40 D.., HS41 D.. 270° Normal 0° 180° Normal Normal Normal 90° Gear Units for Trolley Drive Systems - Operating Instructions... -
Page 17: Hk40D
HK40D... 06 009 000 HK40D... 270° Normal 0° 180° Normal Normal Normal 90° Gear Units for Trolley Drive Systems - Operating Instructions... -
Page 18: Hs50 D
HS50 D.., HS60 D.. 06 010 000 HS50 D.., HS60 D.. Normal 270° 0° 180° Normal Normal Normal 90° Gear Units for Trolley Drive Systems - Operating Instructions... -
Page 19: Technical Data
The following table shows the lubricant filling quantities with respect to the mounting positions M1 – M4. It is essential to use the oil level screw as an indicator of the correct lubricant quantity during filling. Filling quantity in liter Gear unit type HW30 0.65 0.65 0.65 0.75 HS40 1.45... -
Page 20: Recommended Lubricants For Sew Drives
Recommended lubricants for SEW drives Recommended lubricants for SEW drives Helical gear units, helical-bevel R 32 R, K, F, S W gear Helical-worm gear units R 302 gear units gear units, parallel gear units units Food Grease Bio oil ind. oil CLP HC CLP (CC) CLP HC... - Page 21 Recommended lubricants for SEW drives Anti-friction It is recommended to change the grease for anti-friction bearings with grease filling at bearing grease the same time that the oil is changed. Manu- Ambient temperature Basis current filling facturer Gear unit anti- mineral Mobilux EP 2 -30 °C to +60 °C...
