Master Label

Enable Match Code Type
Identical to "Match Code Type," on page 2-22. Instructs the scanner to compare bar
code labels being scanned with a master label and may under certain conditions send
out a relay driver signal and update internal counters.
If no master label has been entered, every decoded label will be a "mismatch" and will
increment the mismatch counter by one.
Enable Match Code Type is intended for use when the scanner is in a triggered mode. If
the Match Code Type is enabled in the Continuous Read mode, the scanner defaults to
Continuous Read 1 Output mode, and the label data must change before the scanner
will output data again, unless a timeout, if enabled, occurs. (See "Operation Menu" on
page 2-16.)
Associated serial commands:
Disable Match Code Type
Disables Match Code Type.
Associated serial commands:
Store Next Label Scanned as Master Label
If Match Code has been enabled, causes the scanner to read the next bar code label
scanned as the master label and stores it in RAM. All subsequently decoded labels are
compared against the new master label information. (See "Match Code Type" on page
2-22.)
Associated serial commands:
Download Master Label Information
Downloads master label information into RAM from the host or a terminal. A stored
master label will not affect standard operation unless Match Code Type is enabled.
The Xs denote alphanumeric data, from 1 to 64 characters.
Associated serial commands:
MS-810 Industrial Scanner User's Manual
<E>
<F>
<G>
<)XXXX)>

Master Label

4-9
