Sample Input Application Diagrams:
Generic Input for Trigger
M S-810
Pin 9 (trigger+)
+
–
Pin 15 (trigger-)
Isolated (trigger only)
MS-810
Pin 9 (trigger+)
Pin 15 (trigger-)
MS-810
Pin 9 (trigger+)
Pin 15 (trigger-)
Non-Isolated
MS-810
Pin 1 (+10-28V)
Pin 9 (trigger+)
Pin 15 (trigger–)
Pin 4 (GND)
Pin 1 (+10-28V)
Pin 9 (trigger+)
Pin 15 (trigger–)
Pin 4 (GND)
MS-810 Industrial Scanner User's Manual
Electrical Specifications
Waveform Characteristics:
SOU RCE
V / I
I IN-HIGH IN-HIGH
V / I
load
IN-LOW IN-LOW
V
O UT
Minimum Input Pulse Width: 60 µS
Max Frequency (
SOURCE
V
SOURCE configured to "SINK"
SOURCE
activation current. Shows optional
PULL-UP resistor.
Source
Signal
SOURCE
V SOURCE configured to "SOURCE"
S OURCE
activation current. Shows optional
Source
PULL-DOWN resistor.
Signal
SOURCE
V
SOURCE configured to "SINK"
10-28V
activation current. Shows optional
PULL-UP resistor.
Source
Signal
SOURCE
V
SOURCE configured to "SOURCE"
10-28V
activation current. Shows optional
Source
PULL-DOWN resistor.
Signal
Minimum Maximum
: 4.8V / 2 mA 28V / 15 mA
: 0V / 0mA 1.5 V / 2.8 mA
): 16.7 kHz
50% duty cycle
