WATTrouter Mx - user manual
Relay output off-delay time
Other parameters
Maximum diameter of wires connected to terminals
Maximum diameter of wires passing through
measuring transformers
Distance of the current sensing module and the
regulator
Distance of the regulator and solid state relay
Working position
Mounting
Overvoltage category
Electric strength
Pollution degree
Operational temperature range
Storage temperature range
Protection (power supply)
IP code
Dimensions (WxHxD)
Weight
Noise level (including power SSRs)
Battery for real-time backup
Warranty period

RECYCLING

After the product life is over the product may be disassembled, recycled or disposed of at a save dumpsite.
Legal regulations regarding electronic waste treatment have to be observed in respective country.
Do not dispose in regular household waste!
How to fit and setup the device
Programmable (minimum of 2s)
2.5 mm
Mx type: 9 mm (including insulation)
Mx 100A type: 14 mm (including insulation)
<2 m (longer wires are acceptable, but they reduce
the accuracy approx. by 0.2% per 2m)
<10 m
Any
Regulator: DIN 35mm or wall mounted using 2 screws
with round or sink head and with diameter of up to
6mm.
Current sensing module: DIN 35mm or wall mounted
using 1 screw with round or sink head and with
diameter of up to 6mm.
III
4 kV / 1 min (between power supply (L1, N) and
pluggable terminals, between power supply and relay
outputs R1 and R2, between power supply and
communication sockets)
2
-20°C to +40°C
-40 °C to +80 °C
B6A
Regulator and current sensing module: IP 20
Regulator: 106x110x64mm (6 modules)
Current sensing module:
Mx type: 70x110x64mm (4 modules)
Mx 100A type: 91x90x65mm (5-6M)
Regulator:400g
Current sensing module:
Mx type: 100g
Mx 100A type: 250g
0 dB(A). Passive cooling only, for power SSRs,
sufficient heat dissipation is required.
CR2032 lithium, usual lifetime> 6 years
36 months
