Electric Circuit
Item
1 Warning Light - Transmission oil temperature
2 Warning Light - Transmission oil pressure
3 Switch - Transmission oil temperature
4 Switch - Transmission oil pressure
5 Audible warning
6 Switch - Parking brake
7 Warning Light - Engine coolant temperature
8 Warning Light - Parking brake 'ON'
9 Switch - Engine coolant
10 Solenoid - Cold start
11 Switch - Cold start
12 Hourmeter
13 Warning Light - Battery charge
14 Warning Light - Engine oil pressure
15 Switch - Engine oil pressure
16 Solenoid - Engine fuel
17 Engine glow plug
18 Alternator
19 Starter
20 Solenoid - Starter
21 Switch - Engine key start
22 Circuit breakers
23 Battery - 12v
24 Battery isolator
10000 - Electric Circuit, Key and Colour Codes
TA9 & TA10 Dumper 0803-4 July 2011
Description
10-4
Cable Colour Codes
B Black
G Green
K Pink
LG Light Green
N Brown
O Orange
P Purple
R Red
S Slate
U Blue
T Turquoise
W White
Y Yellow
8005-0833A
