Operator's Manual
GTH-5519
GTH-5519
Serial number range
From serial n.: 19388
To serial n.: 24471
(Perkins Tier III)
From serial n.: 19006
(Deutz Tier III)
To serial n.: 25040
With Maintenance
Information
First Edition
Eleventh Printing
Part No.
57.0009.0412
