- Page 1 FSW50 Pallet Wrapping Machine OPERATION MANUAL Machine Semi-Automatic Pallet Wrapping Machine Model FSW50 Date February 2018 Issue FPA002...
-
Page 2: Table Of Contents
6. Suggested Maintenance and Trouble Shooting 6.1 Suggested Maintenance 6.2 Warranty Periods 6.3 Fromm Service Solutions 6.4 Possible troubleshooting causes and remedies 7. Contact Fromm Packaging FSW50 Semi-Automatic Pallet Wrapping Machine Operation Manual | FPA001 | Oct 2017 | Page 2 ... -
Page 3: General Information
5. Do not stand on or across from the machine during operation. 6. When a problem does occur, please check the troubleshooting section for more information and advice. FSW50 Semi-Automatic Pallet Wrapping Machine Operation Manual | FPA001 | Oct 2017 | Page 3 ... -
Page 4: Specification
Turntable Maximum Speed: 12 RPM Maximum Load: 1.2 M (wide) x 1.2 M (long) x 2M (height) 1.8M Maximum Wrap Diagonal Max. Load Weight: 2000 kg FSW50 Semi-Automatic Pallet Wrapping Machine Operation Manual | FPA001 | Oct 2017 | Page 4 ... -
Page 5: Machine Dimensions
2.1 Machine Dimensions FSW50 Semi-Automatic Pallet Wrapping Machine Operation Manual | FPA001 | Oct 2017 | Page 5 ... -
Page 6: Safety Precautions
8. Do NOT remove or modify the fixed lower and upper limit switch stops. This may cause personal injury and/or damage to the machine. FSW50 Semi-Automatic Pallet Wrapping Machine Operation Manual | FPA001 | Oct 2017 | Page 6 ... -
Page 7: Operation Of The Control Panel
OPERATION OF THE CONTROL PANEL FSW50 Semi-Automatic Pallet Wrapping Machine Operation Manual | FPA001 | Oct 2017 | Page 7 ... -
Page 8: Control Button Explanations
2. Wrapping tension on the package edge and side are the same. 3. After setting the wrapping tension, it is suitable for most packages and no need to make adjustments. FSW50 Semi-Automatic Pallet Wrapping Machine Operation Manual | FPA001 | Oct 2017 | Page 8 ... - Page 9 The turntable speed is 12 RPM. EMGERGENCY STOP Press this button for any emergency situation. MAIN POWER This turns power OFF or ON. FSW50 Semi-Automatic Pallet Wrapping Machine Operation Manual | FPA001 | Oct 2017 | Page 9 ...
-
Page 10: User Panel
FILM JAWS OPEN DELAY – Sets the delay for the clamps to release the film after wrap. FILM OFF DELAY – Sets the time delay for film stop out from the carriage. FSW50 Semi-Automatic Pallet Wrapping Machine Operation Manual | FPA001 | Oct 2017 | Page 10 ... -
Page 11: Film Loading And Threading
4. Place film loosely between door and pre-stretch rollers, then close the door and ensure that the door is correctly locked. See Figure 1. Film Loading FSW50 Semi-Automatic Pallet Wrapping Machine Operation Manual | FPA001 | Oct 2017 | Page 11 ... -
Page 12: Pre Stretch Percentage Change
5.1 Pre-Stretch Percentage change The standard gears on the FSW50 is set to perform 230% or 300% pre-stretch ratio. To change different ratio, please follow the instructions below. 200% & 250% pre-stretch ratio is also available, please consult your supplier for details. -
Page 13: Suggested Maintenance And Trouble Shooting
With technical offices in Sydney, Brisbane and Melbourne metro areas we are on hand to ensure your equipment is running smoothly. Customers located outside metropolitan areas we offer phone support and can organise onsite technical support when required. FSW50 Semi-Automatic Pallet Wrapping Machine Operation Manual | FPA001 | Oct 2017 | Page 13 ... -
Page 14: Possible Troubleshooting Causes And Remedies
Please refer to illustration 5-2, remove mast covers and check for proper tension to the drive chain. Adjust if necessary. Adjust the M10 screw clockwise or counter-clockwise for proper tension. FSW50 Semi-Automatic Pallet Wrapping Machine Operation Manual | FPA001 | Oct 2017 | Page 14 ... -
Page 15: Contact Fromm Packaging
7. CONTACT FROMM PACKAGING AUSTRALIA For any questions please contact Fromm Packaging Australia Phone: 1800 023 890 Email: info@fromm-pack.com.au Postal Address: PO Box 4016, Mt Ommaney QLD 4074 FSW50 Semi-Automatic Pallet Wrapping Machine Operation Manual | FPA001 | Oct 2017 | Page 15 ...
