- Page 1 FSW30 Pallet Wrapping Machine OPERATION MANUAL Machine Semi-Automatic Pallet Wrapping Machine Model FSW30 Date April 2018 Issue FPA002...
-
Page 2: Table Of Contents
5. Suggested Maintenance and Trouble Shooting 5.1 Suggested Maintenance 5.2 Warranty Periods 5.3 Fromm Service Solutions 5.4 Possible troubleshooting causes and remedies 6. Contact Fromm Packaging FSW30 Semi-Automatic Pallet Wrapping Machine Operation Manual | FPA002 | April 2018 | Page 1... -
Page 3: General Information
5. Avoid film winded underneath the turntable. 6. Do not stand on or across the machine during operation. 7. When problem occurs, please read section 5, Suggested Maintenance and Trouble Shooting. FSW30 Semi-Automatic Pallet Wrapping Machine Operation Manual | FPA002 | April 2018 | Page 2... -
Page 4: Specification
Options: 1.80 meters dia. Turntable. 2.6 & 3.0 meters wrapping height Top pressure plate driven by motor Ramp Mechanical roping FSW30 Semi-Automatic Pallet Wrapping Machine Operation Manual | FPA002 | April 2018 | Page 3... -
Page 5: Machine Dimensions
Machine Dimensions FSW30 Semi-Automatic Pallet Wrapping Machine Operation Manual | FPA002 | April 2018 | Page 4... -
Page 6: Machine Description
Machine Description TOWER CONTROL BOX MOTOR COVER CARRIAGE TURNTABLE SEAT FSW30 Semi-Automatic Pallet Wrapping Machine Operation Manual | FPA002 | April 2018 | Page 5... -
Page 7: Operation
No. of wraps. Up or Down Height from Key Lock Manual turntable Rotate Stop Reset Setting Dial/Enter Clockwise “+” Start Counterclockwise “–“ Press to “Enter” FSW30 Semi-Automatic Pallet Wrapping Machine Operation Manual | FPA002 | April 2018 | Page 6... - Page 8 Press the START button to complete the programmed cycle. EMGERGENCY STOP Press this button for any emergency situation. MAIN POWER This turns power OFF or ON. FSW30 Semi-Automatic Pallet Wrapping Machine Operation Manual | FPA002 | April 2018 | Page 7...
-
Page 9: Electrical
Control & wiring box DC 24V 50W Machine power use 1.5 KW Overall power required 1.7 KW Power Cable Minimum 1.25mm Machine input 240V/1 PHASE/50Hz FSW30 Semi-Automatic Pallet Wrapping Machine Operation Manual | FPA002 | April 2018 | Page 8... -
Page 10: Suggested Maintenance And Trouble Shooting
With technical offices in Sydney, Brisbane and Melbourne metro areas we are on hand to ensure your equipment is running smoothly. Customers located outside metropolitan areas we offer phone support and can organise onsite technical support when required. FSW30 Semi-Automatic Pallet Wrapping Machine Operation Manual | FPA002 | April 2018 | Page 9... -
Page 11: Possible Troubleshooting Causes And Remedies
2. Check if the safety pedal switch is faulty. Carriage Safety Door. 1. Check if carriage safety door is open. 2. Check if the safety switch is faulty. Stop Button Check stop pushbutton. FSW30 Semi-Automatic Pallet Wrapping Machine Operation Manual | FPA002 | April 2018 | Page 10... -
Page 12: Contact Fromm Packaging
6. CONTACT FROMM PACKAGING AUSTRALIA For any questions please contact Fromm Packaging Australia Phone: 1800 023 890 Email: info@fromm-pack.com.au Postal Address: PO Box 4016, Mt Ommaney QLD 4074 FSW30 Semi-Automatic Pallet Wrapping Machine Operation Manual | FPA002 | April 2018 | Page 11...
