Table of Contents

Installation & Maintenance Instructions
Important Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Specifi cations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 4
Cycle Times . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Cost of Operation per Month . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Service. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 - 6
Changing Filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Changing UVC Lamps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Tracking fi lter and UV Lamp Service Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 - 8
Performance Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Electrical Schematic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Product Label Placement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
IMPORTANT SAFETY INSTRUCTIONS
Before installing the Trio 1200/2000 Healthy Home Air Purifi cation System, inspect for any signs of damage. During
handling and installation, take care to protect the catalytic honeycomb side of the product from physical damage, as
the aluminum-titanium core is very soft and can be easily damaged.
WARNING WARNING - Always unplug the power cord from the Trio 1200/2000 Healthy Home Air Purifi cation System
when changing the fi lter or UVC germicidal lamps. Never look into an illuminated ultraviolet lamp without
proper eye protection as severe damage to the eyes can result. This product is rated for standard ambient
air temperatures during heating and air-conditioning functions and not rated for elevated air temperatures
in excess of 125 degrees Fahrenheit.
Do not attempt to clean the catalytic honeycomb core with cleaning solutions. The catalyst is radiated with short
wave ultraviolet light during period of non-air fl ow and is self-cleaning. If there is build up blocking the catalytic cells,
sit the unit on end, on a fl at surface, with electrical enclosure facing up. Use low-pressure, compressed air to blow
the surface of the catalytic cells free of blockage.
Do not install insulation within 76MM or 3 inches of Luminaries.
Access for service is required when mounting above ceilings or behind walls.
Do not install in a position where the interior model can gravity fall from an elevated position and cause injury to
the people or equipment below.
Use a qualifi ed installer/technician when installing this system. Installation shall meet all applicable local/state codes.
Air Purifi cation System
