Belling CH302TX
Date: 14/08/18

Advertisement

Table of Contents
loading

Related Manuals for Belling CH302TX

Summary of Contents for Belling CH302TX

  • Page 1 Belling CH302TX Date: 14/08/18...
  • Page 2 NZ - New Zealand DE - Germany NL - Netherlands AU - Australia ES - Spain To contact Belling about your appliance, please call: Warranty Registration Customer Care Helpline 0800 952 1068 0344 815 3746 in case of difficulty within the UK...
  • Page 3 INTRODUCTION This user guide book is designed to help you through each step of owning your new product. Please read it carefully before you start using your appliance, as we have endeavored to answer as many questions as possible, and provide you with as much support as we can. General information, spares and service information is available from our website.
  • Page 4 SAFETY WARNING • If the hob surface is cracked, broken or shattered, switch off the appliance to avoid the possibility of electric shock and call for a service engineer’s visit. • During use the appliance becomes hot. Care should be taken to avoid touching heating elements.
  • Page 5 • Always switch off your appliance and allow it to cool down before you clean any part of it. • Although every care has been taken to ensure this appliance has no sharp edges. We recommend that you wear protective gloves when installing and moving this appliance.

  • Page 6: Getting To Know Your Product

    USING YOUR APPLIANCE Getting to know your product Note: Your appliance layout may differ depending on the model. Control Panel Hob functions Power/Timer regulating touch Timer control control Keylock control On/Off control Heating zone selection controls...

  • Page 7: Touch Controls

    Before using the Hob • Read this guide, taking special note of the ‘Safety Warnings’ section. • Remove any protective film that may still be on your hob. Touch controls Use the flat of your finger, not the tip. The controls respond to touch, so you don’t need to apply any pressure.

  • Page 8: Start Cooking

    Start cooking After switching the hob on, the buzzer will beep once. All the indicator lights, light up for a second and go out, to indicate that the ceramic hob is now in standby mode. 1. Touch the On/Off control key. All the indicators show “-” 2.

  • Page 9: Finish Cooking

    Finish cooking Touch the relevant heating zone selection control. Turn the cooking zone off by touching the minus key repeatedly until the display shows 0, or by touching the plus and minus keys together. Turn the whole cooktop off by touching the On/Off control key.

  • Page 10: Timer Control

    Locking and unlocking the Controls • You can lock the controls to prevent unintended use (for example children accidentally turning the cooking zones on). • When the controls are locked, all the controls except the On/Off control are disabled. To lock 1.

  • Page 11: Using The Timer As A Minute Minder

    Using the Timer as a Minute Minder If you are not selecting any cooking zone 1. Make sure the hob is turned on. Note: you can use the minute minder even if you’re not selecting any cooking zone. If you don’t start to select a minute minder duration time within 1 minute of switching the hob on, then the hob will switch off again automatically.
  • Page 12 Setting the timer to turn one or more cooking zones off automatically 1. First ensure that the relevant cooking zone has been selected and has a power level selected. Touch the zone selection key for the zone you wish to programme. 2.
  • Page 13 Note: • The red dot shows next to the relevant power level indicator to indicate which zone is being controlled by the timer. • If you want to change the time after the timer is set, you have to start from step 1. •...

  • Page 14: Over Temperature Protection

    Over-Temperature Protection A temperature sensor measures the temperature underneath the glass. If an excessively high temperature is observed, then the heating elements will be switched off automatically. Residual Heat Warning “H” will show which cooking zone is hot to touch. It will disappear when the surface has cooled down to a safe temperature.
  • Page 15 CLEANING YOUR APPLIANCE Do’s Note: Always switch off your appliance and allow it to cool down before you clean any part of it. Note: Please take extra care when cleaning over the symbols on the control panel, as this can lead to them fading.

  • Page 16: Installation

    Installation Preparing the worktop cut out To avoid danger or damage to the appliance, do not attempt to disassemble the appliance or replace parts yourself. Always request a service visit. Make a cut-out in the worktop according to the dimensions shown in the table. For the purpose of installation and use, a minimum of 5cm space shall be preserved around the hole.
  • Page 17 Min.30mm A(mm) B(mm) C(mm) 50 mini 20 mini Air intake Air exit 5mm WARNING: Ensuring Adequate Ventilation In order to prevent accidental touching of the hot area underneath the hob, and to prevent the risk of electric shock, install a wooden isolation plate with screws, at least 50mm underneath the base of the hob, unless the hob is installed directly over an oven.

  • Page 18: Before Locating The Fixing Brackets

    Before locating the fixing brackets The unit should be placed on a stable, smooth surface (use the packaging). Fit the installation seal and gently insert the hob into the worktop cutout hole. Then working from the un- derneath, use the four installation brackets to secure the hob in position. The installation brackets can be inverted to suit the thickness of the work surface.

  • Page 19: Connecting The Hob To The Mains Power Supply

    Connecting the hob to the mains power supply WARNING: This appliance must be earthed. 1. If the cable is damaged or needs replacing, this should be done by an after-sales technician using the proper tools, so as to avoid any accidents. 2.
  • Page 20 Please keep this handbook for future reference, or for anyone else who may use the appliance.
  • Page 21 Please keep this handbook for future reference, or for anyone else who may use the appliance.
  • Page 22 Please keep this handbook for future reference, or for anyone else who may use the appliance.

  • Page 24: Technical Data

    TECHNICAL DATA Hob Details Cooking hob CH302TX Cooking Zones 2 Zones Supply Voltage 220-240V~ 50Hz or 60Hz Installed Electric Power 2700 - 3300W Product Size D x W x H(mm) 288 x 520 x 55 Building-in Dimensions A x B (mm) 268 x 500 Weight and Dimensions are approximate.
