6. Click the Settings tab.
7. Click the Advanced button.
8. Click the S3DuoVue tab. The screen shown at the right appears.
9. Select the CRT box to enable display on an external monitor.
10. You can also use the FN+F8 hot keys to cycle through the CRT/LCD settings.
79_0100_001
© 2001 Itronix Corporation. All rights reserved.
Making Connections
Your computer is equipped with a full array of ports and connectors, including standard input/output
(I/O) ports for quickly and easily adding peripheral devices such as printers and monitors. Refer to
documentation included with individual devices for details on connecting these devices to your
computer. Your computer may also include modem and LAN (optional) ports, offering advanced
communications technology.
GoBook Pro Help

Right Side Connectors

1 Serial Port
The 9-pin serial port can be used to connect your computer to serial devices such as fax/modem or
serial mouse. This port
2 LAN RJ-45 Jack (optional)
With the built-in Ethernet LAN combo, you can make LAN connections without installing PC cards.
Connection speed is 10/100 Mbps.
3 USB (Universal Serial Bus) Ports (2 Connectors)
The Universal Serial Bus (USB) is the latest standard for attaching input devices, scanners, and other
devices to a PC. USB devices can be chained together on a single cable. USB is 1.1 compliant.
file://C:\WINDOWS\TEMP\~hh6357.htm
3. Making Connections Topics
is identified as COM1 and is 16550A compatible.
