Armstrong Design Envelope 4302 Installation & Operating Instructions Manual page 25

descrip tion
Language
Local/remote control
Local reference
Active setup
Programming setup
Copying of setups
lcp copy
Display scaling of motor frequency
Display line 2
Display line 1.1
Display line 1.2
Display line 1.3
Local control/confi guration
Local stop
Local jog
Local reversing
Local reset of trip
Lock for data change
Operating state at power up,
Local control
Confi guration
Torque characteristics
Motor power
Motor voltage
Motor frequency
Motor current
Rated motor speed
Resonance damp
dc braking time
dc brake cut -in frequency
Motor thermal protection
dc braking voltage
Start voltage
Start compensation
u/f ratio
Slip compensation
dc holding voltage
Brake cut -out frequency
Brake cut -in frequency
Rotation direction
Minimum frequency
Maximum frequency
Reference/feedback range
Minimum reference
Maximum reference
Ramp up time 1
Ramp down time 1
Ramp up time 2
Ramp down time 2
Jog ramp time
Quick stop ramp down time
Jog frequency
Reference function
Preset reference 1
(copy of parameter 241)
Preset reference 2
Catch up/slow down value
Current limit for motor mode
Frequency bypass bandwidth
Frequency bypass 1
Frequency bypass 2
Preset reference 1
(copy of parameter 215)
Preset reference 2 - 7
Design Envelope 4302 ivs and 4382 ivs vertical
in-line pumping unit with integrated controls
par ameter sensorless
001 English
002 Local
003 0.000
004 Multi setup
005 Active setup
006 No copy
007 No copy
008 1.00
009 Frequency [hz]
010 Sensorless head [kpa]
011 Sensorless power [W]
012 Sensorless fl ow [L/s]
013 lcp dig control/par 100
014 Enable
015 Enable
016 Disable
017 Enable
018 Not locked
019 Auto restart
100 Speed open loop
101 Constant torque
102 Unit dependant
103 Unit dependant
104 Unit dependant
105 Unit dependant
106 Unit dependant
117 Off
126 10.0 seconds
127 Off
128 Disable
132 Off
133 Motor dependant
134 100.0%
135 Motor dependant
136 0.00%
137 Off
138
3.0hz
139
3.0hz
200 132hz ctr-clockwise
201
21hz
202 50hz (60 some models)
203 Min- max
204 0hz
205 50hz (60 some models)
207 10.00 seconds
208 3.0 seconds
209 3.0 seconds
210 3.0 seconds
211 10.00 seconds
212 3.0 seconds
213
50hz
214 Sum
215 000.00%
216 000.00%
219 000.00%
221 100%
229 Off
230
0.00 hz
231
0.00 hz
241 000.00%
242 - 247 000.00%
o per ati n g i n struct i o n s
open loop closed loop
English English
Remote Remote
0.000 0.000
Setup 1 Setup 1
Active setup Active setup
No copy No copy
No copy No copy
1.00 1.00
Frequency [hz] Frequency [hz]
Reference [%] Reference [Unit]
Motor current [Amps] Feedback [Amps]
Power [kW] Power [kW]
lcp dig control/Par 100 lcp dig control/par 100
Enable Enable
Disable Disable
Disable Disable
Enable Enable
Not locked Not locked
Local = Stop Local = Stop
Speed open loop Process closed loop
Variable torque – med Variable torque – med
Unit dependant Unit dependant
Unit dependant Unit dependant
Unit dependant Unit dependant
Unit dependant Unit dependant
Unit dependant Unit dependant
Off Off
10.0 seconds 10.0 seconds
Off Off
Disable Disable
Off Off
Motor dependant Motor dependant
100.0% 100.0%
Motor dependant Motor dependant
100.0% 100.0%
0% 0%
3.0hz 3.0hz
3.0hz 3.0hz
132hz ctr-clockwise 132hz ctr-clockwise
0hz 0hz
50hz (60 some models) 50hz (60 some models)
Min- max Min- max
0hz (Sensor min)
50hz (60 some models) (Sensor max)
10.00 seconds 10.00 seconds
3.0 seconds 3.0 seconds
3.0 seconds 3.0 seconds
3.0 seconds 3.0 seconds
10.00 seconds 10.00 seconds
3.0 seconds 3.0 seconds
50hz 50hz
Sum Sum
000.00% As required [%]
000.00% 000.00%
000.00% 000.00%
100% 100%
Off Off
0.00 hz 0.00 hz
0.00 hz 0.00 hz
000.00% As required [%]
000.00% 000.00%
in stal l a t io n &
25
