- Page 1 LV-67M Mini-ITX Motherboard User’s Manual Edition 1.8 2016/04/11...
- Page 2 LV-67M User’s Manual Copyright Copyright 2013, all rights reserved. This document is copyrighted and all rights are reserved. The information in this document is subject to change without prior notice to make improvements to the products. This document contains proprietary information and protected by copyright. No part of this document may be reproduced, copied, or translated in any form or any means without prior written permission of the manufacturer.
- Page 3 LV-67M User’s Manual Packing List: Please check the package content before you starting using the board. 1 x LV-67M Mini-ITX Motherboard (include Cooler Fan) 2 x SATA Cable 1 x DC Power Cable (OALSATA3-L / 1040529) (OALDC-A / 1040433) 1 x Power Cable...
-
Page 4: Table Of Contents
LV-67M User’s Manual Index Chapter 1 <Introduction> ................4 1.1 <Product Overview> ................. 4 1.2 <Product Specification> ................5 1.3 <Mechanical Drawing> ................6 1.4 <Block Diagram> ..................7 Chapter 2 <Hardware setup> ............8 2.1 <Connector Location and Reference> ............. 8 2.1.1 <Internal connectors list>... -
Page 5: Chapter 1
1.1 <Product Overview> Generation Intel® Core™ i7, i5, i3, LV-67M is Mini-ITX Motherboard which supports 5 Celeron Mobile Processor and features Intel DH82QM87 chipset, integrated HD Graphics, DDR3L memory, Realtek High Definition Audio, Intel Gigabit LAN, Serial ATA with AHCI and RAID function for a system. -
Page 6: Product Specification
LV-67M User’s Manual 1.2 <Product Specification> System Gen Intel® Core™ i7, i5, i3, Celeron Mobile Processor Processor FCBGA1364 package Chipset Intel® DH82QM87 PCH 2 x DDR3L SO-DIMM 1333/1600 MHz up to 16GB Memory Support Non-ECC, unbuffered memory only Watchdog Timer... -
Page 7: Mechanical Drawing
LV-67M User’s Manual 1.3 <Mechanical Drawing>... -
Page 8: Block Diagram
LV-67M User’s Manual 1.4 <Block Diagram> PCIe x16 PTN3460 PCIe x16 DDR3L 1 x LVDS Channel A SO-DIMM 1 x DisplayPort DDR3L Processor Channel B SO-DIMM 1 x DVI-I PCIe x1 1 x VGA I210-AT SATA3 PCIe x1 4 x SATA3 I217-LM USB3.0... -
Page 9: Chapter 2
LV-67M User’s Manual Chapter 2 <Hardware setup> 2.1 <Connector Location and Reference> CN_CRT CD_IN CN_LVDS CN_INV CN_AUDIO CN_LPC CN_DIO DC_IN SIMM CN_SMBUS MINI_CARD2 CPUFAN CN_IR PCIe x16 MINI_CARD1 CN_COM5/6 CN_COM3/4 CN_USB3 JFRNT SATA3-1 SATA3-2 SATA3-3 SATA3-4 CN_USB2-1 SO-DIMM2 SO-DIMM1 CN_USB2-2... -
Page 10: Internal Connectors List
LV-67M User’s Manual 2.1.1 <Internal connectors list> Connector Function SO-DIMM1/2 204-pin DDR3 SO-DIMM slot SATA3-1/2/3/4 7-pin Serial ATA3 connector CN_AUDIO 5 x 2-pin audio pin header CN_DIO 6 x 2-pin GPIO pin header 6 x 2-pin LPC pin header CN_LPC... -
Page 11: Jumper Location And Reference
LV-67M User’s Manual 2.2 <Jumper Location and Reference> JCSEL1 JCSEL2 JVLCD JMSATA JRTC JVUSB 2.2.1 <Jumper list> Jumper Function Power mode select JRTC CMOS Normal/Clear Setting JVUSB USB 5V/5VSB Setting JVLCD Panel Voltage Setting JMSATA MiniCard1 mSATA Setting JCSEL1 COM2 RS-232, RS422, RS485 setting or IrDA setting... -
Page 12: Installing The Memory
LV-67M User’s Manual 2.3 <Installing the Memory> In the process, the board must be powered off. 1. Put the memory tilt into the slot. Note the Memory notch key aligned slot key. 2. Then press down till lock into the mounting notch. -
Page 13: Clear Cmos And Power On Type Selection
LV-67M User’s Manual 2.4 <Clear CMOS and Power on type selection> JRTC: Clear CMOS data jumper Jumper settings Function Clear CMOS Normal (Default) JAT: AT/ATX mode select jumper Jumper settings Function AT mode ATX mode (Default) JRTC -12-... -
Page 14: I/O Interface
LV-67M User’s Manual 2.5 <I/O interface> 2.5.1 <Serial ATA interface> SATA3-1/2/3/4: SATA 7-pin connector Signal Support RAID0, 1, 5, 10. SATA3-1 SATA3-2 SATA3-3 SATA3-4 When use RAID function, it need to enter the BIOS set RAID mode first. [Advanced] > [HDD Configuration] > [Interface Combination] > [RAID]... - Page 15 LV-67M User’s Manual At boot time, press <CTRL + I> to enter the RAID configuration menu. If this screen stop time is too short, it can be set in the BIOS. [HDD Configuration] > [Software Feature Mask Configuration] > [OROM UI Normal...
-
Page 16: Ethernet Interface
LV-67M User’s Manual 2.5.2 <Ethernet interface> The board Integrated I210-AT and I217-LM Gigabit Ethernet which supports WOL on rear I/O. The I217-LM support Intel® AMT 9.0 feature, if want to use, need to enable in the BIOS. (Note that your CPU must support vPro technology, ex: i7-4700EQ) - Page 17 LV-67M User’s Manual CN_CRT CN_LVDS JVLCD CN_INV CN_CRT: VGA 16-pin header (Pitch 2.00mm) Signal Signal GREEN BLUE DETECT DETECT HSYNC VSYNC Note that pin 5, 10 active low. -16-...
- Page 18 LV-67M User’s Manual CN_LVDS: LVDS 40-pin connector ( Model: HIROSE DF13-40DP-1.25V compatible Signal Signal Set by JVLCD Set by JVLCD A_LVDS_0- B_LVDS_0- A_LVDS_0+ B_LVDS_0+ A_LVDS_1- B_LVDS_1- A_LVDS_1+ B_LVDS_1+ A_LVDS_2- B_LVDS_2- A_LVDS_2+ B_LVDS_2+ A_LVDS_CLK- B_LVDS_3- A_LVDS_CLK+ B_LVDS_3+ A_LVDS_3- B_LVDS_CLK- A_LVDS_3+ B_LVDS_CLK+...
-
Page 19: Audio Interface
LV-67M User’s Manual 2.5.4 <Audio interface> CDIN CN_AUDIO Rear Audio Jack Line in Line out Mic in CDIN: CD-ROM audio input 4-pin header (Pitch 2.54mm) Signal CD_L CD_R CN_AUDIO: Front panel audio 10-pin header (Pitch 2.54mm) Signal Signal MIC_L MIC_R... -
Page 20: Usb Interface
LV-67M User’s Manual 2.5.5 <USB interface> USB3.0-2 USB3.0-1 Type: 5V/5VSB Type: 5VSB JVUSB CN_USB3 CN_USB2-1/2 Type: USB2.0, 5VSB Type: USB3.0, 5V/5VSB -19-... - Page 21 LV-67M User’s Manual CN_USB3: Front panel USB3.0 20-pin header (Pitch 2.00mm) Signal Signal Set by JVUSB Set by JVUSB SSRX0- SSRX1- SSRX0+ SSRX1+ SSTX0- SSTX1- SSTX0+ SSTX1+ DATA0- DATA1- DATA0+ DATA1+ CN_USB2-1/2: Front panel USB2.0 10-pin header (Pitch 2.54mm) Signal...
-
Page 22: Serial Port Interface
LV-67M User’s Manual 2.5.6 <Serial Port interface> COM2 COM1 Type: RS232/422/485 JCSEL1 COM5/6 JCSEL2 COM3/4 -21-... - Page 23 LV-67M User’s Manual COM1: RS232 DB9 connector Signal Signal Set by JP1 COM2: RS232/422/485 DB9 connector Signal Signal DCD/ 422TX-/ 485- RXD/ 422TX+/ 485+ TXD/ 422RX+ DTR/ 422RX- Set by JP2 Use JCSEL1 and JCSEL2 to select communication mode COM3/4: COM 20-pin header (Pitch 2.54 x 1.27mm)
- Page 24 LV-67M User’s Manual COM5/6: COM 20-pin header (Pitch 2.54 x 1.27mm) Signal Signal DCD1 RXD1 TXD1 DTR1 DSR1 RTS1 CTS1 DCD2 RXD2 TXD2 DTR2 DSR2 RTS2 CTS2 JP1, JP2, JP3, JP4: COM1, COM2, COM3, COM4 pin-9 setting Jumper settings Function...
-
Page 25: Expansion Slot
LV-67M User’s Manual 2.5.7 <Expansion slot> MINI_CARD2 SIMM PCIe x16 MINI_CARD1 JMSATA <MiniPCIe> MINI_CARD1 and MINI_CARD2 have do some special design to compatible our mini-PCIe card. (ex: MPX-574D2, MPX-210D2 etc) MINI_CARD1 support mSATA set by JMSATA, and MINI_CARD2 support SIM card to use 3G module. - Page 26 LV-67M User’s Manual <SIM> This is for 3G miniPCIe card which doesn’t have SIM slot. Slide the direction of the arrow open the cover. Then press down and slide the Insert the SIM card and make direction of the arrow close the sure the direction is correct cover.
-
Page 27: Front Panel Switch And Indicator
LV-67M User’s Manual 2.5.8 <Front panel switch and indicator> JFRNT JFRNT: Front panel switch and indicator 14-pin header (Pitch 2.54mm) Signal Signal HDD_LED+ Power_LED+ HDD_LED- Reset+ Power_LED- Reset- Speaker+ Power_ON+ Power_ON- Speaker- -26-... -
Page 28: Gpio And Other Interface
LV-67M User’s Manual 2.5.9 <GPIO and Other interface> CN_LPC CPUFAN CN_DIO CN_SMBUS CN_IR SYSFAN When using GPIO function, please note: As Output: Open-drain, most applications need use an external pull up resistor. (If not may cause damage) As Input: TTL-level. - Page 29 LV-67M User’s Manual CN_LPC: LPC 12-pin header (Pitch 2.00mm) Signal Signal -LFRAME LAD3 LAD2 LAD1 LAD0 3.3V SERIRQ 3.3VSB CN_LPC support TPM module. CN_SMBUS: SMBus 5-pin header (Pitch 2.54mm) Signal VCC (5V) SMBDAT SMBCLK CN_IR: IrDA 5-pin header (Pitch 2.54mm)
-
Page 30: Power Supply
LV-67M User’s Manual 2.6 <Power supply> 2.6.1 <Power input> DC_IN The DC_IN support 9~24V wide voltage input. Note that the DC_IN and ATX do not use at the same time, it will certainly cause damage. DC_IN: ATX12V 4-pin connector Signal... -
Page 31: Power Output
LV-67M User’s Manual 2.6.2 <Power output> It is supply to the HDD, CD-ROM or other device. If using DC_IN as input, that ATX will as output. ATX: main power 24-pin connector (As output) Signal Signal 3.3V 3.3V 3.3V 3.3V Note that Maximum output power: 12V/2A, 5V/3A, 3.3V/3A... -
Page 32: Appendix A
LV-67M User’s Manual Appendix A <Flash BIOS> A.1 <Flash tool> The board is based on Phoenix BIOS and can be updated easily by the BIOS auto flash tool. You can download the tool online at the address below: http://www.commell.com.tw/Download/BIOS/FPT9.rar The tool’s file name is “fpt.exe”, it’s the utility that can write the data into the BIOS flash chip and update the BIOS. -
Page 33: Appendix B
LV-67M User’s Manual Appendix B <LCD Panel Type select> According your panel, it need to select the correct resolution in the BIOS. If there is no fit your panel type, please feedback for us to make OEM modol. BIOS panel type selection form (BIOS Version:1.0) -
Page 34: Appendix C
LV-67M User’s Manual Appendix C <Programmable GPIO > The GPIO’ can be programmed with the MS-DOS debug program using simple IN/OUT commands. The DC characteristics please refer to GPIO paragraph (Page25). GPIO -o 2E 87 ;enter configuration -o 2E 87... -
Page 35: Appendix D
LV-67M User’s Manual Appendix D <Programmable Watch Dog Timer> Timeout value range 1 to 255 Minute and Second Program sample Watchdog timer setup as system reset with 5 second of timeout -o 2E 87 ;enter configuration -o 2E 87 -o 2E 07 -o 2F 08 ;select Logical Device... -
Page 36: Contact Information
Taiwan Commate computer Inc. 19F., NO.94, Sec. 1, Xintai 5 Rd., Xizhi Dist., New Taipei Address City 22102, Taiwan. +886-2-26963909 +886-2-26963911 Website www.commell.com.tw info@commell.com.tw (General infomation) E-mail tech@commell.com.tw (Technical Support) Commell is a brand name of Taiwan Commate computer Inc. -35-...
