Mar-18
22,000kg AIR/HYDRAULIC GARAGE JACK
Safe
Max Lift
Working
Height
Capacity
22,000kg
356mm
OWNER'S MANUAL
PRODUCT CODE: BPROAJ22T
Min Lift
Height
215mm
Made in China to TQB Brands Pty Ltd specifications
Visit us at www.tqbbrands.com.au
Hydraulic
Air Supply
Lift
Pressure
141mm
90-120psi
Product Code: BPROAJ22T
Overall
Dimensions mm
525(L)x265(H)x215(W)
Advertisement
Related Manuals for Borum BPROAJ22T
Summary of Contents for Borum BPROAJ22T
- Page 1 Mar-18 Product Code: BPROAJ22T OWNER’S MANUAL PRODUCT CODE: BPROAJ22T 22,000kg AIR/HYDRAULIC GARAGE JACK Safe Max Lift Min Lift Hydraulic Air Supply Overall Working Height Height Lift Pressure Dimensions mm Capacity 22,000kg 356mm 215mm 141mm 90-120psi 525(L)x265(H)x215(W) Made in China to TQB Brands Pty Ltd specifications...
-
Page 2: Table Of Contents
Mar-18 Product Code: BPROAJ22T WARNING IMPORTANT: READ ALL INSTRUCTIONS BEFORE USE WARNING The instructions and warnings contained in this manual should be read and understood before using or operating this equipment. Do not allow anyone to use or operate this equipment until they have read this manual and have developed a thorough understanding of how this equipment works. -
Page 3: Safety Instructions
Mar-18 Product Code: BPROAJ22T SAFETY INSTRUCTIONS WARNING FAILURE TO READ THESE WARNINGS MAY RESULT IN PROPERTY DAMAGE & PERSONAL INJURY Support load by appropriate means after Only lift areas of the vehicle designated by lifting the vehicle manufacturer. -
Page 4: Assembly, Operation, Preventitive Maintenance
ASSEMBLY, OPERATION, PREVENTITIVE MAINTENANCE 1. FEATURES The Borum Air/Hydraulic garage jack utilises compressed air to activate a booster cylinder, to move hydraulic oil within the cylinder up & down. It adopts an industrial hydraulic design combination of compressed air and hydraulic pressure, to create, strong jacking capacity and low lifting clearance in one jack. - Page 5 Mar-18 Product Code: BPROAJ22T 4. OPERATION Lifting Attach air supply hose to fitting in handle control valve. (90 -120 PSI / 14 cfm). Position the jack in accordance with the vehicle manufacturer's instructions. Centre load on saddle. Rotate control valve clockwise and hold to raise the piston, release control valve when desired height is reached.
- Page 6 Mar-18 Product Code: BPROAJ22T 7. MAINTENANCE Monthly maintenance is recommended. Lubrication is critical to jacks as they support heavy loads. Any restriction due to dirt, rust, etc, can cause either slow movement or cause extremely rapid jerks damaging the internal components. The following steps are designed to keep the jack well maintained and operational.
-
Page 7: Troubleshooting
Mar-18 Product Code: BPROAJ22T TROUBLESHOOTING PROBLEM POSSIBLE CAUSE ACTION Jack will not lift Release valve in wrong Move release valve to UP position. position. Low/no oil in reservoir. Fill with oil and bleed Air-locked system. -
Page 8: Parts List
Mar-18 Product Code: BPROAJ22T PARTS LIST Part # Description Part # Description S001 Oil Cylinder Assembly S009 Handle Assembly S002 Oil Drain Valve Assembly S010 Extension S003 Pump Assembly S011 Tie In S004 Air Hose S012 Tank S005 Tank Cover... - Page 9 Mar-18 Product Code: BPROAJ22T Part # Description Part # Description Locking Ring Screw Extension Screw Spacer Piston Screw Nut O-Ring Guide Ring Oil Tank Cap O-Ring O-Ring Screw Tie-In Spring Oil Tank Base Dustproof Ring Screw Nut Guide Ring Steel ball...
-
Page 10: Warranty
Product Code: BPROAJ22T WARRANTY Borum products have been carefully tested and inspected before shipment and are guaranteed to be free from defective materials and workmanship for a period of 12 months from the date of purchase except where tools are hired out when the guarantee period is ninety days from the date of purchase.
