Product Code: BTJ35TA
OWNER'S MANUAL
PRODUCT CODE: BTJ35TA
35,000kg AIR/HYDRAULIC TRUCK JACK
Safe Working
Max Lift
Min Lift
Hydraulic
Screw
Air Supply
Capacity
Height
Height
Lift
Adjustment
Pressure
35,000kg
533mm
255mm
155mm
123mm
110-125psi
Made in China to TQB Brands Pty Ltd specifications
Visit us at www.tqbbrands.com.au
Advertisement
Table of Contents
Related Manuals for Borum BTJ35TA
Summary of Contents for Borum BTJ35TA
- Page 1 May-19 Product Code: BTJ35TA OWNER’S MANUAL PRODUCT CODE: BTJ35TA 35,000kg AIR/HYDRAULIC TRUCK JACK Safe Working Max Lift Min Lift Hydraulic Screw Air Supply Capacity Height Height Lift Adjustment Pressure 35,000kg 533mm 255mm 155mm 123mm 110-125psi Made in China to TQB Brands Pty Ltd specifications...
-
Page 2: Table Of Contents
May-19 Product Code: BTJ35TA WARNING IMPORTANT: READ ALL INSTRUCTIONS BEFORE USE WARNING The instructions and warnings contained in this manual should be read and understood before using or operating this equipment. Do not allow anyone to use or operate this equipment until they have read this manual and have developed a thorough understanding of how this equipment works. -
Page 3: Safety Instructions
May-19 Product Code: BTJ35TA SAFETY INSTRUCTIONS WARNING FAILURE TO READ THESE WARNINGS MAY RESULT IN PROPERTY DAMAGE & PERSONAL INJURY Support load by appropriate means after Only lift areas of the vehicle designated by lifting the vehicle manufacturer. -
Page 4: Assembly, Operation, Preventitive Maintenance
ASSEMBLY, OPERATION, PREVENTITIVE MAINTENANCE 1. FEATURES The Borum Air/Hydraulic Truck Jack utilises compressed air to activate a booster cylinder, to move hydraulic oil within the cylinder up & down. It adopts an industrial hydraulic design combination of compressed air and hydraulic pressure, to create, strong jacking capacity and low lifting clearance in one jack. - Page 5 May-19 Product Code: BTJ35TA 4. OPERATION Lifting Attach air supply hose to fitting in handle control valve. (110 -125 PSI / 14 cfm). Position the jack in accordance with the vehicle manufacturer's instructions. Centre load on saddle. Rotate control valve clockwise and hold to raise the piston, release control valve when desired height is reached.
- Page 6 May-19 Product Code: BTJ35TA 7. MAINTENANCE Monthly maintenance is recommended. Lubrication is critical to jacks as they support heavy loads. Any restriction due to dirt, rust, etc, can cause either slow movement or cause extremely rapid jerks damaging the internal components. The following steps are designed to keep the jack well maintained and operational.
-
Page 7: Troubleshooting
May-19 Product Code: BTJ35TA TROUBLESHOOTING PROBLEM POSSIBLE CAUSE ACTION Jack will not lift Release valve in wrong Move release valve to UP position. position. Low/no oil in reservoir. Fill with oil and bleed Air-locked system. -
Page 8: Parts Diagram
May-19 Product Code: BTJ35TA PARTS DIAGRAM Made in China to TQB Brands Pty Ltd specifications Page 8 Visit us at www.tqbbrands.com.au... -
Page 9: Parts List
May-19 Product Code: BTJ35TA PARTS LIST Part # Description Part # Description Bolt Bolt Handle Wheel Right Side Plate Handle-2 Circlip Lock Lever Wheel Lever Bolt Adjustable Frame O-Ring Base Plate O-Ring Left Side Plate Packing Handle Socket Throttle Cardan joint-1... -
Page 10: Warranty
Product Code: BTJ35TA WARRANTY Borum products have been carefully tested and inspected before shipment and are guaranteed to be free from defective materials and workmanship for a period of 12 months from the date of purchase except where tools are hired out when the guarantee period is ninety days from the date of purchase.
