Borum BAJ2080 Owner's Manual

10,000-25,000-50,000kg air/hydraulic garage jack
Hide thumbs

Advertisement

Table of Contents

10,000-25,000-50,000kg AIR/HYDRAULIC
1st Stage
2nd Stage
Lifting
Lifting
Capacity
Capacity
50,000kg
25,000kg
OWNER'S MANUAL
PRODUCT CODE: BAJ2080
GARAGE JACK
3rd Stage
Max Lift
Lifting
Capacity
10,000kg
Made in China to TQB Brands Pty Ltd specifications
Visit us at www.tqbbrands.com.au
Min Lift
Height
Height
300mm
150mm
Product Code: BAJ2080
Air Supply
Package Size
Pressure
(mm)
100-145psi
710x370x290

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BAJ2080 and is the answer not in the manual?

Questions and answers

Related Manuals for Borum BAJ2080

Summary of Contents for Borum BAJ2080

  • Page 1 Product Code: BAJ2080 OWNER’S MANUAL PRODUCT CODE: BAJ2080 10,000-25,000-50,000kg AIR/HYDRAULIC GARAGE JACK 1st Stage 2nd Stage 3rd Stage Max Lift Min Lift Air Supply Package Size Lifting Lifting Lifting Height Height Pressure (mm) Capacity Capacity Capacity 50,000kg 25,000kg 10,000kg 300mm...
