BECK-O-TRONIC 5
Version: Centronic
Assembly and Operating Instructions
en
Door control unit
Important information for:
• Fitters / • Electricians / • Users
Please forward accordingly!
These instructions must be kept safe for future reference.
4005 630 111 0b 10/08/2018
Becker-Antriebe GmbH
Friedrich-Ebert-Straße 2-4
35764 Sinn/Germany
www.becker-antriebe.com
Advertisement
Table of Contents
Related Manuals for Becker Beck-O-Tronic 5
Summary of Contents for Becker Beck-O-Tronic 5
- Page 1 BECK-O-TRONIC 5 Version: Centronic Assembly and Operating Instructions Door control unit Important information for: • Fitters / • Electricians / • Users Please forward accordingly! These instructions must be kept safe for future reference. 4005 630 111 0b 10/08/2018 Becker-Antriebe GmbH Friedrich-Ebert-Straße 2-4...
-
Page 2: Table Of Contents
Table of contents General ........................ 3 Warranty ...................... 3 Safety instructions .................... 4 Intended use ...................... 6 Product overview .................... 7 Installation...................... 8 Wiring ........................ 9 Settings ....................... 9 Explanation of displays and buttons ............... 11 Programming the remote control................ 12 Deleting transmitters.................... 13 Overwriting the master transmitter ................ 14 Status display ...................... 14 Maintenance ....................... 15... -
Page 3: General
General This control unit is a high-quality product with many features and advantages: • simple, convenient connection • easy to handle and highly flexible • modular system with plug-in remote control • for optical and electric safety edges Please observe these Assembly and Operating Instructions when installing and setting the equipment. -
Page 4: Safety Instructions
Safety instructions The following safety instructions and warnings are intended to avert hazards and to prevent property damage and personal injury. Please keep the instruction manual safe! Caution • Work on the electrical equipment may only be carried out by a qualified electrician. •... - Page 5 • If there is no fixed stop, e.g., when using roller doors, the customer must ensure that the roller shutter curtain is protected and cannot cause any dangerous situ- ations, e.g., by overrunning a limit position. • The control unit is designed to have a service life of 100,000 operating cycles.
-
Page 6: Intended Use
the control unit. In light of this, the installer / person re- sponsible for the system must carefully check the set- tings made and modify them as necessary. Intended use The type of control unit described in these instructions may only be used for the opera- tion of tubular drives in roller doors which have fixed stops at the limit positions or a cover on the barrel (EN 12453). -
Page 7: Product Overview
Product overview 1. "Impulse" button (IMP) 2. Hand-held transmitter 3. Mains plug Mains plug The control unit is disconnected from the power supply by removing the mains plug. Door movement is no longer possible. Caution Work on the electrical equipment may only be carried out by a qualified electrician. -
Page 8: Installation
Installation Check that the transmitter and receiver are functioning perfectly prior to installation in the desired location. Open the cover of the control unit. Unplug and remove the “pulse” button from the control unit and carefully place the cover to one side. Remove the re- quired cut-outs in the bottom part of the housing. -
Page 9: Wiring
Wiring Connect the individual pieces of equipment as shown in the connecting diagram. Caution Electrical work may only be carried out by qualified elec- tricians or trained personnel. Always disconnect the safety mains plug before connecting the equipment. The connection to the building wiring system must be estab- lished in accordance with the Machinery Directive using an adequately sized mains disconnection device. - Page 10 Caution In order to operate a roller door in maintained operation, the system must be equipped with a closing edge safety device. Please ensure that main and auxiliary closing edges are sufficiently protected and the permitted closing edge forces are not exceeded! Outdoor light The light is switched on for 2 minutes at every door movement.
-
Page 11: Explanation Of Displays And Buttons
Explanation of displays and buttons A) Radio PRG button B) Programming button on the radio re- ceiver C) Programming button on the transmit- D) LED E) DIP switch (must be set to OFF) F) LED G) Control button... -
Page 12: Programming The Remote Control
Programming the remote control Caution If a radio control system is used, the person operating the door must have full view of the door and its surroundings while the door is moving and ensure that he/she is clear of all hazardous areas. It is only possible to operate the control unit with one transmitter when a safety device is connected. -
Page 13: Deleting Transmitters
Programming additional transmitters In addition to the master transmitter, up to 7 further trans- mitters can be programmed in the radio receiver. Press the programming button (C) of the master transmitter for 3 seconds. ▻ The LED (D) lights up once to confirm. Now press the programming button of a new transmitter which has not yet been pro- grammed in the tubular drive for 3 seconds. -
Page 14: Overwriting The Master Transmitter
Deleting all transmitters (except the master transmitter) Press the programming button (C) on the master transmitter for 3 seconds. ▻ The LED (D) lights up once to confirm. Press the programming button (C) on the master transmitter again for 3 seconds. ▻... -
Page 15: Maintenance
Maintenance This control unit is maintenance-free. Cleaning Only clean the outside of the housing with a suitable cloth. Do not use cleaning agents, as these may damage the plastic. Technical data Dimensions of the housing (W x H x D) 155 x 130 x 50 mm Housing material Degree of protection... -
Page 16: What To Do If
What to do if...? Problem Remedy The door cannot be operated using the Check the safety devices. The control unit transmitter. only reacts to the transmitter if all the safety devices are active and the door moves in maintained operation. The LED (D) flashes when the transmitter is operated. -
Page 17: Connecting Diagram
Connecting diagram Radio PRG Light barrier e.g., key switch white Optical safety edge brown from FRABA green Electric safety edge Emergency stop circuit or anti-unrolling device Drive Outdoor light... -
Page 18: Declaration Of Conformity
Declaration of conformity...
