5.2.5

AUX / MIC Section

The AUX / MIC section on the rear panel.
▪ The AUX input is for connecting a standard line-level source such as an MP3 player or CD
player. Like the MIC
passing through the tone EQ stage, which is controlled by the
panel (see also ↑5.4.1, AUX / MIC
ing equipment via aux inputs, please read the separate Setup Guide as instructed in
↑1.3.1, The Setup
▪ The MIC input lets you connect a microphone to the Z2. The signal is sent straight to the
Master outputs and is equally distributed between the left and right channels (for a more
detailed description, please read the separate Setup Guide as instructed in
Setup Guide).
Both MIC and AUX inputs can be used simultaneously — they are simply mixed together and
sent through the tone EQ stage and then through to the outputs. The signal does not pass
through any of TRAKTOR's FX or through the Z2's channel EQs or Filters.
The MIC input can be muted with the on/off switch (see also
the top panel.
5.2.6

GND (Ground) Screws

The ground screws on the rear panel.
input, the AUX input is sent straight to the output summing bus after
Controls). (For a more detailed description of connect-
Guide.)
TRAKTOR KONTROL Z2 Hardware Reference
TONE knob on the Z2's top
↑1.3.1, The
↑5.4.1, AUX / MIC Controls) on
