Go Rhino DOMINATOR D2 SERIES Installation Instructions page 2

T-PLATE
STEP 2. INSERT (1) OF THE T-PLATES THROUGH THE OBLONG HOLE IN THE BODY PANEL AND POSITION
THE PLATE INSIDE THE PANEL AS SHOWN.
T-PLATE
3/8" FLAT WASHER,
LOCK WASHER & HEX NUT
3/8" X 1 ¼" HEX BOLTS,
LOCK WASHERS, & FLAT WASHERS
MOUNTING BRACKET
STEP 3. ATTACH ONE OF THE MOUNTING BRACKETS TO THE BODY PANEL USING THE T-PLATE (2) 3/8" X 1
¼" HEX BOLTS, (3) 3/8" FLAT WASHERS, (3) 3/8" LOCK WASHERS AND (1) 3/8" HEX NUT. HAND TIGHTEN.
