convenience concepts ASHLEY LOUNGE Assembly Instructions

ASSEMBLY INSTRUCTIONS

We have designed our furniture with you , the customer in mind . Our clear , easy to follow ,

step by step instructions will guide you through the project from start to finish .

Feel confident that this will be a fun and rewarding project . The final product will be a quality

piece of furniture that will go together smoothly and give years of enjoyment .

Please do not return to the store

STOP

Broken or missing parts?

Need help with assembly?

If you have any questions just call 1-800-468-6447 or email us at

parts@convenience-concepts.com

ASHLEY LOUNGE

143357GY

143357T

Table of Contents

Need help?

Do you have a question about the ASHLEY LOUNGE and is the answer not in the manual?

Page 1 ASHLEY LOUNGE 143357GY 143357T ASSEMBLY INSTRUCTIONS We have designed our furniture with you , the customer in mind . Our clear , easy to follow , step by step instructions will guide you through the project from start to finish .
Page 2 Hardware List Big ﬂat washer (11pcs) Long bolt ( 11pcs ) Short bolt ( 4pcs ) Flat washer (4pcs) Allen wrench (1pc) Lock washer (11pcs) Washer (2pcs) Panel List Back support (1pc) Seat (1pc) Front leg (2pcs) Left rear leg (1pc) Right rear leg (1pc) Page 2 of 4...
Page 3 Step 1 1.Insert left rear leg and right rear leg into back support as shown . Step 2 1.Connect left back leg and right back leg to back support using long bolts(A) , big ﬂat washers (C) , lock washers (E) and allen wrench (F) .
Page 4 Step 3 1.Gently pull back fabric on seat as shown. 2.Connect seat to back support as shown using long bolts(A) , big ﬂat washers (C) , lock washers (E) and allen wrench (F) . 3.Gently replace fabric on seat Step 4 1.Connect front legs to unit as shown using washers (G) , short bolts(B) ,...
