If the keypad lock is enabled in a mode that requires a password, pressing Lock
display the password entry block (Figure 12).
1. Navigate from number to number by pressing Left
2. Select the number in each position with the Up or Down button.
3. Press Enter
previous screen.

Figure 12: Password Entry Block

If the password entry block remains idle for several seconds it will time out and restore
the home screen.

4.4.6 Set Liquid Measure Units

This system features U.S. and metric units. Select the preferred units by pressing Left
or Right

Figure 13: Set Unit

to submit the completed password or Exit
(Figure 13) and press Save to retain the setting.
19
OPERATION
will
or Right .
to return to the
