MODEL & SERIAL NUMBER / REPLACEMENT PARTS
Figure 27.1 - Model Number Designations
Separated Combustion
Unit Con guration
PTS - Propeller Unit, 150-400MBH
BTS - Blower Unit, 150-400MBH
MBH Input
(refer to page 22)
150 - 150 000 BTU/hr input
200 - 200 000 BTU/hr input
250 - 250 000 BTU/hr input
Heat Exchanger Type
S - Stainless Steel
Figure 27.2 - Serial Number Designations
S 3 0 0 1
SERIAL NUMBER
SPO MODEL
MOTOR SUPPLIER
05 - Universal 18 - Franklin
15 - Marathon 38 - A.O. Smith
Replacement Parts
When requesting parts please contact your local representative. Please have full model and serial number available. If you require
assistance in locating your representative, please call the number located on the back page.
S 3 0 0 1
NUMÉRO DE
SÉRIE
SPO Modèle
MOTEUR FOURNISSEUR
05 - Universal 18 - Franklin
15 - Marathon 38 - A.O. Smith
(Remove access cover to locate)
PTS 200 A S 01
etc.
A - Aluminium
Ignition Type
S - Direct Spark
Power Code
(see pages 14 and 17)
01 - 115 V/60 Hz/1 ph
02 - 115/230V/60 Hz/1 ph
etc.
(Remove access cover to locate)
CONTROL SUPPLIER
01 - RobertShaw 09 - White Rogers
05 - Honeywell 17 - United Tech
08 - Fenwal
0 0 1 7 9
UNIT SERIES
00 - Original 01 - Modified
FAN VENDOR CODE
20 - Morrison 01 - Revcor
10 - Lau 08 - Brookside
19 - Air Drive
FOURNISSEUR DU RÉGULATEUR
01 - RobertShaw 09 - White Rogers
05 - Honeywell 17 - United Tech
08 - Fenwal
0 0 1 7 9
CONFIGURATION
00 - Original 01 - Modifié
CODE DU FOURNISSEUR
VENTILATEUR
20 - Morrison 01 - Revcor
10 - Lau 08 - Brookside
19 - Air Drive
11 S C A N
Factory Installed Option Digit
N - None
Future
A - All
Dev Digit
Fan Guard Digit
N - None (all blower models)
S - Standard
F - Fingerproof
Control Code Type
(refer to page 21)
11 - Natural gas, single-stage
12 - Natural gas, two-stage
21 - Propane, single-stage
22 - Propane, two-stage
GAS VALVE SUPPLIER
01 - RobertShaw
05 - Honeywell
09 - White Rogers
YEAR OF MANUFACTURE
0 1 0 9 8
WEEK OF
MANUFACTURE
Same as Requirements
Planning Shop Calendar
FOURNISSEUR DE
ROBINET DE GAZ
01 - RobertShaw
05 - Honeywell
09 - White Rogers
ANNÉE DE FABRICATION
0 1 0 9 8
SEMAINE DE
FABRICATION
6-561.11
SPO NUMBER
1 2 3 4 1 0 0 0 0
SEQUENTIAL NUMBER
Number varies from 0000 to 9999.
Each unit within same week of
manufacture is to have unique number.
SPO NUMÉRO
1 2 3 4 1 0 0 0 0
NUMÉRO SÉQUENTIEL
Nombre variable compris entre 0000 et 9999.
