Multistore LSS 550 User Manual

Multistore
PARTS IDENTIFICATION LIST FOR MODEL LSS 550
2 x PANELS - 1 x LEFT HAND (A) , 1 x RIGHT HAND (E)
TOP AND BOTTOM FIXED SHELF 1 x TOP (D) 1 x BOTTOM (C)
1 x KICK (B) 575mm x 61mm
2 x Pullout Shelves (G & H)
1 x BACK PANEL (F) 488mm x 604mm
Industries (Aust) Pty Ltd
548mm W x 381mm D
HARDWARE LIST
NO MODEL
1
2
3
4
5
6
9 Nevilles St, Underwood, Brisbane, QLD 4119
Ph: 07 3208 6799 Fax: 07 3290 6332
Int Ph: +61 7 3208 6799 Int Fax: +61 7 3290 6332
Email: sales@multi-store.com.au
www.multi-store.com.au
550mm H x 608mm W x 430mm D
575mm H x 424mm W
DESCRIPTIONS
M50 x 5mm
CONFIRMAT SCREWS
WHITE CAPS
NAILS
FIXING OF BACK
5/8 x 6 WOOD SCREWS
FIXING SHELF RUNNER
EURO SCREW
ATTACHMENT OF RUNNERS
SHELF RUNNERS
550mm H x 426mm W x 16mm D
QTY
10
10
25
8
8
4
