WASHING MACHINE INSTALLATION

Removal of the packaging material

Packaging material protects your washing machine during transportation. Packaging materials are
environmentally friendly and recyclable. Recycling saves raw material resources and protect the environment.

Removal of the locking screws

Before you start using the machine, it is ESSENTIAL that you remove the locking screws at the rear of the
machine which protect the drum during transport. Damage caused by running the washing machine with the
locking screws is not covered under warranty
4
X
Using the supplied key,
loosen the lock screws by
turning counterclockwise.

Setting the adjustable feet

• Do not place the machine on carpets or similar surface that would prevent ventilation beneath the
washing machine.
• To ensure quiet operation vibration-free, position the machine on a firm non-slip surface.
• You can level the machine using the adjustable feet.
• Turn to adjust the feet up or down.
• Never compensate for uneven floor by inserting cardboard, wood or similar materials under the washing
machine.
• Diagonal check: When you push on the washing machine corners, it should not sway. Check both
diagonals. If the washing machine sways, adjust the feet length.
• When cleaning the floor under the machine, be careful not to change the level of the washing machine.
4
X
Remove the loosened
locking screws.
Up
Insert the supplied plugs in
the holes from the locking
screws.
Lock nut
Down
4
X
Keep the locking screws
for possible future
transportation.
