- Page 1 English EWS 60141 SW EWS 70142 SW WASHING MACHINE INSTRUCTION MANUAL Always read the safety&use instructions carefully before using your appliance for the first time. The user´s manual must be always included.
-
Page 3: Safety Instructions
WASHING MACHINE SAFETY INSTRUCTIONS Read carefully and save for future use! Warning: The safety measures and instructions, contained in this manual, do not include all conditions and situations possible. The user must understand that common sense, caution and care are factors that cannot be integrated into any product. -
Page 4: Washing Machine
WASHING MACHINE 5. Improperly performed repairs can expose the user to significant hazards for which the manufacturer is not liable. 6. Repairs may only be carried out by a qualified person and a designated service provider. 7. In the event of a fault or during cleaning and maintenance, the washing machine is only electrically disconnected from the mains when: - the mains plug of the washing machine is pulled out of the socket,... - Page 5 of 3 should be denied access unless they are under constant supervision. 16. Keep away from children the small parts supplied in the bag with documentation. 17. Do not expose the appliance to direct sunlight, do not use it outside, and do not expose it to rain.
- Page 6 26. This washing machine is intended for indoor use only. 27. Do not install the appliance in wet or damp rooms, as well as in rooms where appear explosive or corrosive gases. 28. This appliance is intended for use by children 8 years of age and older and persons with reduced physical or mental abilities or lack of experience and knowledge, provided they are under supervision or given instructions concerning use of the appliance in a safe manner...
-
Page 7: Children's Safety
• Never open the detergent drawer while the machine is running. • Never force open the door of the washing machine while it is running. • Before opening the door, make sure that no water remains in the drum. Do not open the washing machine door if you see water. -
Page 8: Product Description
PRODUCT DESCRIPTION (illustration) Top cover Inlet hose Control panel Power cord Detergent dispenser Drum Here you can find the label with the serial number Door Service filter Drain hose Note: The product description is for reference only, please refer to the actual product as standard. Accessories •... - Page 9 Unpacking the washing machine Warning: • Packaging material (e.g. foil, polystyrene) can be dangerous for children. • There is a risk of suffocation! Keep the packaging materials away from the children. Remove the cardboard box and polystyrene wrapping. Pull out the washing machine and remove the base packaging. Make sure the small foam triangle has been removed together with the bottom one.
-
Page 10: Prior To Use
Connecting water drain hose The drain hose can be positioned in three different ways (see picture on the right): By the edge of the sink with a plastic hook (not included). Make sure that the hose is well fixed to the sink. Into a drain pipe located at a height of at least 60 cm and not exceeding 90 cm. -
Page 11: Laundry Preparation
Laundry preparation Follow the instructions of the labels on the garment. Divide the laundry according to type (cotton, synthetics, delicate, wool, etc.), washing temperature (cold, 30 °, 40 °, 60 °, 90 °) and degree of soiling (slightly soiled, soiled, heavily soiled). Never wash coloured and white laundry together. -
Page 12: Detergent Dispenser
Hang to dry Do not tumble dry Hang when wet Can be cleaned with gasoline, alcohol, Can be cleaned with benzene, Can be cleaned with perchlorethylene, and trifluorotrichloroethane perchlorethylene R11, R113 and gasoline NOTE: Be careful not to exceed the maximum load of the drum, as this would lead to poor washing results and wrinkling of the laundry. -
Page 13: Starting The Washing Programme
Liquid detergent partition Before using a liquid detergent, it is necessary to fold If you want to use a washing powder, you need to lift the partition for liquid detergents with a measuring the partition: cup: Starting the washing programme •... -
Page 14: Additional Functions
The activation of an option is indicated by a Slightly soiled laundry permanently lit icon. Normally soiled laundry Confirming an additional function Heavily soiled laundry This button is used to confirm the selected Additional function* additional function. Start/Pause This button allows you to scroll through the different washing options. - Page 15 OVERVIEW OF WASHING PROGRAMMES Wash cycle duration* Cotton 6 kg Cold - 90 °C Prewash, Extra rinse or Soak, Delay 0 - maximum 1:37 2:07 rinse, Eco, Soil level setting Linen, pillowcases, cotton 7 kg and linen tablecloths. ECO 40-60 6 kg According to the type of According to...
- Page 16 Wash cycle duration* Jeans/dark clothing 6 kg Cold - 60 °C Prewash, Extra rinse or Soak, Delay 1:48 2:08 0 - maximum rinse, Eco, Soil level setting Dark cotton and jeans. 7 kg Self cleaning 6 kg Cold - 90 °C Extra rinse or Soak, Delay rinse, Soil 1:41 1:58...
- Page 17 A further soaking stage ensures that detergent residues and pollen/allergen particles are thoroughly removed, making the washing more efficient. The maximum quantity of the program is 5 shirts or 5 T-shirts. TABLES OF CONSUMPTION VALUES EWS 60141 SW (6 kg model) Power Residual Rated...
-
Page 18: Cleaning And Maintenance
EWS 70142 SW (7 kg model) Power Residual Rated Program Water con- Max. consump- moisture Programme capacity duration sumption temperature tion kWh/ content in (%) (kg) (H:min) (l/cycle) (°C) cycle at 1400 rpm. Cotton 20 °C 1:45 0.20 Cotton 60 °C with 2:38 1.26 prewash... -
Page 19: Drum Cleaning
Drum cleaning Rust left by metal objects inside the drum is immediately removed with chlorine-free cleaning agents. Never use wire. Do not put clothes in the washing machine while the drum is being cleaned. Cleaning door seals and glass After each wash, wipe the glass and gasket to remove streaks and stains. If the gunk builds up, it can cause leaks. -
Page 20: Troubleshooting
NOTE: Filter cover may vary by model. Warning: • Make sure the washing machine has completed the wash cycle and is empty. Before cleaning the drain pump filter, switch off the washing machine and unplug it from the power outlet. •... -
Page 21: Error Messages On The Display
Description Solution • Make sure the red light is not on. • Make sure that the appliance is not in soak mode Can not open the door. or that the optional Soak function is not active. • Push the door from the closing side or push lightly while trying to open it. - Page 22 Error code Cause Solution F03 (flashing indicators 2, The washing machine can't Switch off the washing machine and restart 3, 5, 6) heat the water. the washing programme. °C °C F04 (indicators 1, 4, 5, 6 Water discharge failure. • Remove the drain hose from the drain flashing) line and make sure it drains directly into...
-
Page 23: Technical Specifications
TECHNICAL SPECIFICATIONS EWS 60141 SW EWS 70142 SW Built-in appliance Maximum load capacity (dry laundry) kg Maximum speed/min. 1400 1400 Dimensions (H × W × D) [mm] 840 × 595 × 438 840 × 595 × 450 Nominal voltage 220-230 ~ 50 Hz... - Page 24 This product complies with the requirements of the EU directives on electromagnetic compatibility and electrical safety and the issue of heavy metals in electrical and electronic equipment. The operating manual is available at www.ecg-electro.eu. Changes of text and technical parameters reserved.
- Page 25 The manufacturer takes no responsibility for printing errors contained in the product’s user’s manual. © GVS.cz 2024...
