- Page 1 Document No.: S01A-FPC-0601A Version No.: V1.01 USER ScanLogic Optical Operating Instructions Part Number: FPC-0601A 1．Optical Fingerprint Reader 2．LCD Screen 3．Digital Pad SecuRam Systems Inc. Page 1...
- Page 2 For installation and wiring refer to the installation instructions. About Default Codes: The ScanLogic Optical has 1 default code 1234567890. However upon enrollment and use of the first fingerprint (ID01), this default code is deleted. It is important to set a new code relative to this fingerprint.
-
Page 3: Table Of Contents
26. Set time delay 27. Unlock with an enrolled user 28. Set number of locks 29. Authorize access to locks 30. Delete one user / all users 31. Wrong entry penalty 32. System info. 33. Specifications SecuRam Systems Inc. Page 3... -
Page 4: Lock Set Up
Now enter the default Administrator Code - which is 1234567890 Important – The ScanLogic Optical has a Multi-Numeric EntryPad which means that a single key on the EntryPad can represent more than one number. In order to enter a “5”, press the button marked “345” just once. -
Page 5: Open The Lock Using An Enrolled Fingerprint
Press “▲” or “▼” to scroll to “Enroll New User”. Press “Menu/OK” again. Place another finger on the fingerprint reader window and hold for the enrollment process to complete. The additional fingerprint is now enrolled as the next available User ID# SecuRam Systems Inc. Page 5... -
Page 6: Set/Change User Code
To Program or “Set” the User Code: Unlock the safe lock system with the fingerprint of ID No.03. The LCD will display “Select Menu” Press “▲” or “▼” to scroll to “Set/Change User Code”. SecuRam Systems Inc. Page 6... -
Page 7: Disable User Code
Unlock the system with an administrator’s fingerprint (ID No. 01 or 02). The LCD will display “Select Menu” Press “▲” or “▼” to scroll to “Disable User”. Press “▲” or “▼” to select the ID No. to disable (e.g. ID 03). Press “Menu/OK”. SecuRam Systems Inc. Page 7... -
Page 8: Enable User
The LCD will display “Select Menu” “Set/Cancel Time Delay”. Press “▲” or “▼” to scroll to Press “Menu/OK”. Press “▲” or “▼” to set time delay (00 to 99 min). Press “Menu/OK”. SecuRam Systems Inc. Page 8... -
Page 9: Time Delay - Unlock With An Enrolled Fingerprint
The EntryPad will start counting down. The LCD screen flashes with remaining time every 15 seconds. Since the Time Window has been set as 5 minutes in this example, a valid SecuRam Systems Inc. Page 9... -
Page 10: Time Delay - Unlock With A User Code
Lock 1, or push “ to unlock Lock 2, or push “ ” unlock Lock 3, or push “ to unlock Lock 4. If setting the number of locks to be 01, after the EntryPad verifies user successfully, the SecuRam Systems Inc. Page 10... -
Page 11: Authorize Access To Locks
The first letter “x” is flashing. Press “▲” or “▼” to toggle this letter to “x”. Press “Menu/OK”. The second letter will flash. Press “▲” or “▼” to toggle this letter to “o”. Press “Menu/OK”. Press “Menu/OK” twice to confirm the condition of Lock 3 and 4. SecuRam Systems Inc. Page 11... -
Page 12: Delete One User
Note: After deleting all users, all the enrolled fingerprints and codes are deleted completely. The Administrators Code is reset to 1234567890 19. Wrong entry penalty (Level 3) Four (4) consecutive invalid code entries initiate a 4-minute penalty time. The LCD will show: SecuRam Systems Inc. Page 12... -
Page 13: Set Security Level
Incorrect fingerprint entries will not initiate penalty time. 20. Set Security Level The ScanLogic Optical has 3 security modes as follows: Level 1: EntryPad can be operated by a code. Level 2: EntryPad must be operated by a fingerprint and its bound code. -
Page 14: Enroll The Second Or Additional Fingerprints And Bound Code
Unlock by an administrator (ID 01 or ID 02) .When the LCD screen shows “Select Menu”, Follow the steps on Pages 6-7 to disable or enable a user. 26. Set time delay (Level 1 & 2) SecuRam Systems Inc. Page 14... -
Page 15: Unlock With An Enrolled User
“System INFO.” Press “Menu/OK” and the LCD will show: This indicates that up to 30 users can be enrolled in the EntryPad and there is no user enrolled currently. The EntryPad firmware version is V9.82110909-27. SecuRam Systems Inc. Page 15... -
Page 16: Specifications
➤Battery Life Span: About 1 year ➤Batter Low Voltage: 5.4± 0.2V ➤Working Temperature: 0℃ ~ + 49℃ ➤Fingerprint Reader Dimension: 6” (L) x 2-12/16” (W) x 1-11/16” (T) ➤Working Humidity (Max): 90% SecuRam Systems, Inc. U.S.A. SecuRam Systems Inc. Page 16...
