- Page 1 User‘s Manual for Procusini 3.0 3D Food Printer for Commercial Use As at Jul 18; EN...
-
Page 2: Table Of Contents
Preparation of the flexible production mat, silicone ............ 12 Preparation of the cartridges ..................13 Commissioning ........................13 Connect Procusini to a WLAN enabled device (AP mode, recommended) ....13 Prepare the first production with the Procusini ............14 Produce with the Procusini ....................17 Turn off the Procusini ...................... - Page 3 User´s Manual for Procusini Upload the specially created objects from the Procusini Club into the user interface..22 Other uses of the Procusini Club ................... 23 Logos ..........................23 Freehand drawing........................23 Text messages ........................24 Trace contours ........................24 3D objects with own foods ....................
-
Page 4: Basic Information
1 Basic Information General description The Procusini is an easy-to-use Procusini for use in commercial kitchen, e.g. in catering, event gastronomy or bakery/confectionery. It consists of a heatable cartridge holder, which is mounted to a positioning unit and operated via WLAN. -
Page 5: Technical Data Procusini (In/°F)
User´s Manual for Procusini Technical data Procusini (in/°F) Production Usability Food with appropriate consistency Technology Layer-by-layer deposition of consumables Heatable Volume of capsule 2 oz Building space 9,8 in 5,9 in 3,9 in Precision 0,004 in ... -
Page 6: Main Components
User´s Manual for Procusini Main components (1)Printing Plate (2)Cartridge holder (3)Fill level display (4)Power Switch (5)Power Supply Socket Schematic overview For questions, please do not hesitate to email us at: service@procusini.com Page 6 of 33... -
Page 7: Qualification Of Personnel
User´s Manual for Procusini 2 Qualification of personnel This machine requires proper training. It is ONLY recommended for use by individuals with sufficient training and/or those that are monitored by a person who has been properly trained on the safety and intended use of the machine. -
Page 8: General Safety Instructions For Machine Operation
General directions Warning: Never leave the Procusini unattended when in use! Warning: High temperatures may develop in the printing head of the Procusini. For this reason, never grasp the printer while in operation. Change the food cartridge only after the... -
Page 9: Setup, Location Of Operation
Setup, location of operation Place the Procusini onto a stable, horizontal, large enough area only. Please note that the production plate moves from right to left when operating and thus requires enough space. Additionally, some movement also occurs vertically. -
Page 10: Use In Accordance With Regulations
Please retain all original packaging as well as all shipping and handling material. This is the only way to assure a successful and safe transport of the Procusini, for instance in the case of a return under warranty! -
Page 11: Liability And Guarantee
Guarantee The guarantee for the Procusini is valid for 6 months starting on the date of purchase. Please preserve all original packaging and transportation packaging in case the device should need to... -
Page 12: Description Ofthe Functions And Operation Of The Machine
4 Description ofthe Functions and Operation of the Machine Procusini and accessories (1) Procusini 3.0; (2) 3 cartridges; (3) 5 dosing tips; (4) 1 cleaning hook; (5) 1 cleaning syringe; (6) 1 scalpel; (7) 1 production plate – standard with magnetic lock; (8) 1 flexible production mat, silicone;... -
Page 13: Preparation Of The Cartridges
The preparation of the cartridges as well as its filling with food are individual for each product and are extensively described in the annex and the application instructions. More information as well as the current application instructions for food items can be found at www.procusini.club. Commissioning a. -
Page 14: Prepare The First Production With The Procusini
For more information, as well as the current application instructions for food, see also www.procusini.club. Tip: For the first production of an object with the Procusini, we recommend starting with our 3D marzipan to get a feel for the handling of the device. - Page 15 User´s Manual for Procusini The "Select food" field appears. Select the food you have previously used, tick the box and confirm with "OK". The message "Calibrate Now?" Appears. For questions, please do not hesitate to email us at: service@procusini.com...
- Page 16 User´s Manual for Procusini Calibration is necessary the first time you use the Procusini and every time you exchange your production documents. Click on "ok" to start the process. Calibration is done using the arrow keys. Attention: Just click on an arrow once, the system remembers the steps and if it clicks too often the device could move into the production file and cause damage to the Procusini •...
-
Page 17: Produce With The Procusini
User´s Manual for Procusini Produce with the Procusini • When the preparations are completed until the first production, you will be taken to the page with the first objects. • For foods that require heating, a red bar appears with the appropriate preheat time. - Page 18 • Here you can, if necessary, readjust the height of the starting point with the arrow keys. • If you are satisfied with the distance, click on "Start" and the Procusini will start production. • Now a progress bar appears.
-
Page 19: Turn Off The Procusini
Recommendations for handling food can be found in the instructions for use and in the Procusini Club. Now press the on / off switch on the Procusini to switch off your device. 5 Create your own objects The Procusini-Club Creating an object with the Procusini Club requires an internet connection. - Page 20 User´s Manual for Procusini • Under Applications you have the different options to create your own objects. • The principle of creating your own template is largely similar for the various applications. • As an example, the procedure with the application "3D objects" is illustrated here.
- Page 21 If you are satisfied with the size of your object, confirm with "Next". • Now assign a name (no special characters). • Click on "Convert file". You will get back to the homepage of the Procusini Club. • To load your own created objects onto the user interface select "File Download" •...
-
Page 22: Upload The Specially Created Objects From The Procusini Club Into The User Interface
Click on the "Upload Objects" button and select your zip folder there (zip folder must not be unzipped!). • Now all your created objects are on their Procusini for the particular food and you can start the production. For questions, please do not hesitate to email us at: service@procusini.com... -
Page 23: Other Uses Of The Procusini Club
User´s Manual for Procusini Other uses of the Procusini Club Logos • Under Applications you will find the function "Logos". • Here you can upload your desired logo. • Indicate your desired dimensions and the food from which you would like to produce the logo. -
Page 24: Text Messages
User´s Manual for Procusini Text messages • Under Applications you will find the function "Text Messages". • Enter your text in the appropriate field. • For texts, first create a line, click on "Add text", then create the second text and add it. -
Page 25: Objects With Own Foods
User´s Manual for Procusini 3D objects with own foods • The expert application allows you to make your own settings. • Select "3D objects with own food". • Now you will be prompted to upload an STL file of your choice as under "3D Objects". -
Page 26: Other Functions Of The User Interface
User´s Manual for Procusini 6 Other functions of the user interface Changing the cartridge Changing the cartridge is possible at any time – even during the production process. Upon request the device completes the commenced object after changing the cartridge. -
Page 27: Alignment Of The Production Plate
User´s Manual for Procusini Alignment of the production plate If you find that the production plate shows different distances to the dosing tip, you will have the opportunity to compensate the distance. To do so, select ”Settings – Alignment“ and follow the instructions on the user interface. -
Page 28: Cleaning The Heatable Stainless Steel Tip
Never use a flexible production mat which has tears or cuts. Standby mode If you do not start a production order for 2 hours, your Procusini goes into standby mode automatically. In order to get started again, press ”Connect“. -
Page 29: Parking
Attention! Firewalls, personal network settings or security clearance as well as corporate networks can cause problems. If you have problems and the Procusini can not be found by the procedures listed below, please wait at least 30 minutes and do not switch off the device. After 30 minutes the Procusini WLAN appears again and you can work with the device as usual. -
Page 30: Windows 7 / Windows 8 / Windows 10
Start the user interface by clicking this new device. Note: If you want to disconnect the Procusini from your network, go to Connections and then to "AP Mode". After that, your device is disconnected from your Internet access and you will find the Procusini WLAN in the Internet access list again. -
Page 31: Troubleshooting
User´s Manual for Procusini 7 Troubleshooting By selecting Procusini you have chosen a product that has a state-of-the-art construction and is operationally safe. Despite this, problems or disturbances may occur. For this reason, a guide to solve potential problems is given in the following: Observe the safety information! After start-up, the 3D printer is not working. -
Page 32: For Questions, Please Do Not Hesitate To Email Us At: Service@Procusini.com
• Check your network and wireless connection as well as the filling level of the cartridge. • Switch off the device, wait at least 20 seconds and turn it back on. • Wait to connect the Procusini, until it moves into the ”Home“ position by itself. This may take several minutes. -
Page 33: Returning Old Devices
Liebigstraße 11 85354 Freising Germany www.procusini.com We hope you have a great time with your Procusini and look forward to hearing your feedback, comments, and creative ideas. Your Procusini-Team For questions, please do not hesitate to email us at: service@procusini.com...
