Connecting MADI

The MADI ports are used for transmission of 64
audio channels (AES10). Two different MADI I/O
confi gurations are available:
1 x SC-Socket
1 x BNC coaxial
SC socket (optical)
MADI output (64 ch), connect for MADI output
signal here.
SC socket (optical)
MADI input (64 ch), connect MADI input signal
here.
SC socket (optical) or BNC socket
(coaxial), 75 Ω
MADI output (64 ch), connect for MADI output
signal here.
SC socket (optical) or BNC socket
(coaxial), 75 Ω
MADI input (64 ch), connect MADI input signal
here.
CHAPTER 4: Operation
2 x SC-Socket
EXBOX.64 Manual - Version 2.0
