NOTE
Both output ports don't carry a signal unless a valid
input signal has been detected at the corresponding
input ports.
MADI 1 LED (green) indicates the use of MADI 1
input and its lock status.
SYNC
LED OFF = no signal
LED ON = signal present
MADI 2 LED (green) indicates the use of MADI 2
SYNC input and its lock status.
LED OFF = no signal
LED ON = signal present
