CHAPTER 7: Technical Data
Dimensions
• Width 140 mm
• Height 42 mm
• Depth 146 mm
Weight
• 0.8 kg
Power Consumption
• 5 W (typical)
Power Supply
• 2 x Hirose socket (HR10)
• 9 V - 24 V DC (external)
WARNING
The connected power supply must provide a current
limiting to a maximum of 2.5 A.
Environmental Conditions
• Operating temperature +5°C up to +45°C
• Relative humidity: 10% - 80%, non condensing
MADI Port BNC coaxial (BNC/SC version)
• 2 x BNC socket (input / output)
• Impedance: 75 Ω
• 0.3 V up to 0.6 V (peak to peak)
CHAPTER 7: Technical Data
EXBOX.64 Manual - Version 2.0
