base control

General

Parameterization
Page 12
1.4
Error Meaning
no.
24 not assigned here
25 Control unit EEPROM / reconciliation error
26 not assigned here
27
Control unit On key
28 not assigned here
29
Control unit Enter key
30 not assigned here
31 not assigned here
32 not assigned here
1) Parameterization of external output enable necessary if no infinite output control is available
The control unit calculates from the current operating data the respective best
operating mode and automatically selects it.The parameters are adjustable.
In order to prevent unintentional changes to pre-set parameters, these param-
eters are code-protected.
Caution!
Never change the value of a parameter if you do not know what it means!
This may cause incorrect behaviour of the control unit!
Do not experiment with parameter settings!
Always call BOGE-Service if you are unsure or have any doubts.
From the main display the first step in parameterization is performed by re-
peated pressing of the Info key
proceeding as follows:
1. Press Enter key
the left, followed by three zeros, the left of which blinks.
2. Press Info key to change the first digit.
3. Press Enter key
4. Press Info key to change the second digit.
5. Press Enter key
6. Press Info key to change the third digit.
7. Press Enter key
set number – if the value is invalid the main display will reappear.
Parameterization of the control
does not open
does not open
, until the display the software-no., and then
→
and the parameterization symbol
→
and now the middle zero blinks.
→
and now the right zero blinks.
→
the display will now branch off depending on the
BOGE base control for screw compressors
Compressor
cut-out
X
X
is shown on
