base control
Operating and control
panel
Position of the
Emergency Stop button
Page 2
1.1
Fig. 1.1: base control operating panel
1 LC display
2 Indicator lamp – Fault (red)
3 Indicator lamp – Ready (green)
4 Info key
5 Enter key
6 On key
7 Off key
Depending on the compressor type the Emergency Stop button is either
mounted on the side (1) or front (2) of the switch cabinet.
Fig. 1.2: Possible positions of the Emergency Stop button: side (1) / front (2)
