CONNECTING THE BATTERY/BATTERIES

The NODE uses one or two standard nine-volt batteries (not included)
to operate the valves and program the controller . The controller can
operate using either a single nine-volt battery or using two nine-volt
batteries . Under normal conditions, the expected life is one year for a
single battery and two years when using two nine-volt batteries .
NOTE: The NODE has non-volatile memory. This
allows the battery to be removed without losing
program information.
To Install the Battery/Batteries
1 . Unscrew the rear body of the NODE body to gain access to the
battery compartment.
2 . Insert the battery/batteries into the battery tray and connect to
the controller using the battery connector.
3 . Make sure that no water is inside the battery compartment.
4 . Screw the NODE rear body back onto the front half.
NOTE: Verify that the seal marker on the rear half
of the NODE lines up with the front half, ensuring
that a proper seal is created.
