Adjustable Back Support; Attach/Remove Mattress - Arjohuntleigh Carevo Instructions For Use Manual

Fig. 1
Fig. 2
Fig. 3

Adjustable Back Support

Some Carevo models (BAC1111-01, BAC1112-01 and
BAC1113-01) are equipped with an electronic adjustable back
support. Use the control panels to operate the adjustable back
support. (See Fig. 1)
Press to raise the adjustable back support.
Press to lower the adjustable back support.
CAUTION
To avoid the Carevo adjustable back support from
electrical overheating during constant use of
lowering/raising, make sure to lower/raise the back
support for a maximum of 2 minutes. Then wait for
6 minutes before lowering/raising the back support
again.

Attach/Remove Mattress

Attach:
Find the position of the drainage outlet and let the mattress
guides fall into the mattress guide holes located on the support
plates.
(See Fig. 2)
Remove:
1 Remove the drainage plug from the mattress.
2 Pull the mattress up and away from the support plates.
(See Fig. 3)
15
